| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (428-13-21001) | TORQUE CONVERTER A. | 1 | SN: 51001- |
|||
| ? | (428-13-21000) | TORQUE CONVERTER A. | 1 | SN: 50001-51000 |
|||
| ? | THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.F4310-51A0 TO F4310-56A0A. | ||||||
| ? | 711-56-31342 | • GEAR | 1 | SN: 50001- |
|||
| ? | 428-13-13130 | • HOUSING | 1 | SN: 50001- |
|||
| ? | 04530-03045 | • BOLT | 2 | SN: 50001- |
|||
| ? | 711-33-13340 | • O-RING (K1) | 1 | SN: 50001- |
|||
| ? | 01011-61685 | • BOLT | 2 | SN: 50001- |
|||
| ? | 01643-31645 | • WASHER | 2 | SN: 50001- |
|||
| ? | 428-13-16910 | • BLOCK | 1 | SN: 50001- |
|||
| ? | 01010-81055 | • BOLT | 2 | SN: 50001- |
|||
| ? | 01643-31032 | • WASHER | 2 | SN: 50001- |
|||
| ? | 428-13-16920 | • TUBE | 1 | SN: 50001- |
|||
| ? | 07042-20108 | • PLUG | 1 | SN: 50001- |
|||
| ? | 428-13-16930 | • TUBE | 1 | SN: 50001- |
|||
| ? | 428-13-16940 | • TUBE | 1 | SN: 50001- |
|||
| ? | 01010-81055 | • BOLT | 2 | SN: 50001- |
|||
| ? | 01643-31032 | • WASHER | 2 | SN: 50001- |
|||
| ? | 07206-30812 | • BOLT | 8 | SN: 50001- |
|||
| ? | 07005-01212 | • GASKET (K1) | 16 | SN: 50001- |
|||
| ? | 04434-00808 | • CLIP | 3 | SN: 50001- |
|||
| ? | 01010-80816 | • BOLT | 3 | SN: 50001- |
|||
| ? | 01643-30823 | • WASHER | 3 | SN: 50001- |
|||
| ? | 711-21-13850 | • NOZZLE | 1 | SN: 50001- |
|||
| ? | 711-56-36950 | • TUBE | 1 | SN: 50001- |
