| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 428-20-15001 | SUPPORT ASS'Y | 1 | SN: 50001- |
|||
| ? | 428-20-15211 | • SHAFT | 1 | SN: 50001- |
|||
| ? | 428-20-15411 | • RETAINER | 1 | SN: 50001- |
|||
| ? | 428-20-15730 | • SEAL,OIL | 1 | SN: 50001- |
|||
| ? | 07000-15160 | • O-RING | 1 | SN: 50001- |
|||
| ? | 01010-61040 | • BOLT | 3 | SN: 50001- |
|||
| ? | 01643-31032 | • WASHER | 3 | SN: 50001- |
|||
| ? | 428-20-15710 | • BEARING | 2 | SN: 50001- |
|||
| ? | 428-20-15740 | • SEAL,OIL | 1 | SN: 50001- |
|||
| ? | 428-20-15231 | • COUPLING | 1 | SN: 50001- |
|||
| ? | 07000-15080 | • O-RING | 1 | SN: 50001- |
|||
| ? | 428-20-15290 | • HOLDER | 1 | SN: 50001- |
|||
| ? | 01011-63035 | • BOLT | 1 | SN: 50001- |
|||
| ? | 428-20-15540 | • SHIM¤ 0.05MM | 3 | SN: 50001- |
|||
| ? | 428-20-15550 | • SHIM¤ 0.1MM | 5 | SN: 50001- |
|||
| ? | 428-20-15560 | • SHIM¤ 0.3MM | 6 | SN: 50001- |
|||
| ? | 428-20-15112 | • HOUSING | 1 | SN: 50001- |
|||
| ? | 07030-01030 | • BREATHER | 1 | SN: 50001- |
|||
| ? | 01010-62485 | BOLT | 6 | SN: 50001- |
|||
| ? | 01643-32460 | WASHER | 12 | SN: 50001- |
|||
| ? | 01580-02419 | NUT | 6 | SN: 50001- |
|||
| ? | 427-20-15510 | SHIM¤ 0.1MM | 5 | SN: 50001- |
|||
| ? | 427-20-15520 | SHIM¤ 0.2MM | 5 | SN: 50001- |
|||
| ? | 427-20-15530 | SHIM¤ 0.5MM | 3 | SN: 50001- |
