| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO. | SERIALNO: |
|||||
| ? | (426-15-00011) | TRANSMISSION ASS'Y | 1 | SN: (3001)- KIT-FLAG: _- SERIALNO: (3001)- |
|||
| ? | (426-15-00020) | TRANSMISSION ASS'Y | 1 | SN: (1973)-(3000) KIT-FLAG: _- SERIALNO: (1973)-(3000) |
|||
| ? | (426-15-00010) | TRANSMISSION ASS'Y | 1 | SN: 10001-(1972) KIT-FLAG: _- SERIALNO: 10001-(1972) |
|||
| ? | THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.2501 TO 2534. | SERIALNO: |
|||||
| ? | (426-15-00302) | • CONTROL VALVE ASS'Y | 1 | SN: (1973)- KIT-FLAG: _- SERIALNO: (1973)- |
|||
| ? | (426-15-00301) | • CONTROL VALVE ASS'Y | 1 | SN: (1370)-(1972) KIT-FLAG: _- SERIALNO: (1370)-(1972) |
|||
| ? | (□426-15-00300) | • CONTROL VALVE ASS'Y | 1 | SN: 10001-(1369) KIT-FLAG: _- SERIALNO: 10001-(1369) |
|||
| ? | THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.2531 TO 2534. | SERIALNO: |
|||||
| ? | 428-15-00120 | • • VALVE ASS'Y,SOLENOID | 1 | SN: (1973)- KIT-FLAG: _- SERIALNO: (1973)- |
|||
| ? | 424-15-00300 | • • VALVE ASS'Y,SOLENOID | 1 | SN: 10001-(1972) KIT-FLAG: _- SERIALNO: 10001-(1972) |
|||
| ? | 424-15-17112 | • • • BODY | 1 | SN: (1973)- KIT-FLAG: _- SERIALNO: (1973)- |
|||
| ? | 424-15-17110 | • • • BODY | 1 | SN: 10001-(1972) KIT-FLAG: _- SERIALNO: 10001-(1972) |
|||
| ? | 07042-20108 | • • • PLUG | 2 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 424-15-17212 | • • • WIRE ASS'Y | 1 | SN: (1973)- KIT-FLAG: _- SERIALNO: (1973)- |
|||
| ? | 424-15-17211 | • • • WIRE ASS'Y | 1 | SN: 10001-(1972) KIT-FLAG: _- SERIALNO: 10001-(1972) |
|||
| ? | 424-15-17230 | • • • GASKET (K3) | 1 | SN: (1973)- KIT-FLAG: _- SERIALNO: (1973)- |
|||
| ? | 568-15-15880 | • • • GASKET (K3) | 1 | SN: 10001-(1972) KIT-FLAG: _- SERIALNO: 10001-(1972) |
|||
| ? | 01220-40310 | • • • SCREW | 4 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 01601-20307 | • • • WASHER,SPRING | 4 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 568-15-15960 | • • • BUSHING | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 568-15-15970 | • • • PAD | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 569-15-37310 | • • • SPOOL | 6 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 07000-71009 | • • • O-RING (K3) | 6 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 424-15-17340 | • • • PLATE | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 561-15-47210 | • • • VALVE,SOLENOID | 6 | SN: (3001)- KIT-FLAG: _- SERIALNO: (3001)- |
|||
| ? | □568-15-17210 | • • • VALVE,SOLENOID | 6 | SN: 10001-(3000) KIT-FLAG: _- SERIALNO: 10001-(3000) |
|||
| ? | 568-15-17260 | • • • • O-RING (K3) | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 07000-31006 | • • • • O-RING (K3) | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 561-15-47230 | • • • • SCREEN | 1 | SN: (3001)- KIT-FLAG: _- SERIALNO: (3001)- |
|||
| ? | 01220-40416 | • • • SCREW | 24 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 01601-20410 | • • • WASHER,SPRING | 24 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 424-15-17160 | • • • PROTECTOR | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 424-15-17150 | • • • STAND | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 01220-40412 | • • • SCREW | 4 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 01601-20410 | • • • WASHER,SPRING | 4 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 568-15-17220 | • • • TERMINAL | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 01220-40310 | • • • SCREW | 4 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 01601-20307 | • • • WASHER,SPRING | 4 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 424-15-17131 | • • • COVER | 1 | SN: (1973)- KIT-FLAG: _- SERIALNO: (1973)- |
|||
| ? | 424-15-17130 | • • • COVER | 1 | SN: 10001-(1972) KIT-FLAG: _- SERIALNO: 10001-(1972) |
|||
| ? | 424-15-17141 | • • • GASKET (K3) | 1 | SN: (1973)- KIT-FLAG: _- SERIALNO: (1973)- |
|||
| ? | 424-15-17140 | • • • GASKET (K3) | 1 | SN: 10001-(1972) KIT-FLAG: _- SERIALNO: 10001-(1972) |
|||
| ? | 01252-40618 | • • • BOLT | 12 | SN: (1973)- KIT-FLAG: _- SERIALNO: (1973)- |
|||
| ? | 01252-40616 | • • • BOLT | 12 | SN: 10001-(1972) KIT-FLAG: _- SERIALNO: 10001-(1972) |
|||
| ? | 01602-20619 | • • • WASHER,SPRING | 12 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 424-15-17121 | • GASKET (K3) | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | (☒424-15-17120) | • GASKET (K3) | 1 | SN: (10001-(1790)) KIT-FLAG: _- SERIALNO: (10001-(1790)) |
|||
| ? | 01011-51040 | • BOLT | 5 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 01010-51085 | • BOLT | 4 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 01643-31032 | • WASHER | 9 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
