| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO. | SERIALNO: |
|||||
| ? | (426-15-00011) | TRANSMISSION ASS'Y | 1 | SN: (3001)- KIT-FLAG: _- SERIALNO: (3001)- |
|||
| ? | (426-15-00020) | TRANSMISSION ASS'Y | 1 | SN: (1973)-(3000) KIT-FLAG: _- SERIALNO: (1973)-(3000) |
|||
| ? | (426-15-00010) | TRANSMISSION ASS'Y | 1 | SN: 10001-(1972) KIT-FLAG: _- SERIALNO: 10001-(1972) |
|||
| ? | THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.2501 TO 2534. | SERIALNO: |
|||||
| ? | (426-15-00302) | • CONTROL VALVE ASS'Y | 1 | SN: (1973)- KIT-FLAG: _- SERIALNO: (1973)- |
|||
| ? | (426-15-00301) | • CONTROL VALVE ASS'Y | 1 | SN: (1370)-(1972) KIT-FLAG: _- SERIALNO: (1370)-(1972) |
|||
| ? | (□426-15-00300) | • CONTROL VALVE ASS'Y | 1 | SN: 10001-(1369) KIT-FLAG: _- SERIALNO: 10001-(1369) |
|||
| ? | THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.2531 TO 2534. | SERIALNO: |
|||||
| ? | 425-15-15210 | • • BODY,VALVE | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 232-15-14230 | • • VALVE | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 232-15-14260 | • • SPRING, (L= 39.4) | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 424-15-15670 | • • STOPPER | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 04025-00640 | • • PIN,SPRING | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 424-15-15391 | • • VALVE | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 424-15-15340 | • • VALVE | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 104-15-25490 | • • VALVE | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 125-15-15290 | • • SPRING | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 104-15-25480 | • • VALVE | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 113-15-25260 | • • SHIM, 0.5MM | 6 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 104-15-25290 | • • SPRING, (L= 62.0) | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 424-15-15321 | • • VALVE | 6 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 424-15-15371 | • • STOPPER | 6 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 568-15-15330 | • • SPRING, (L= 78.0) | 6 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 424-15-15441 | • • COLLAR | 1 | SN: (1370)- KIT-FLAG: _- SERIALNO: (1370)- |
|||
| ? | 424-15-15440 | • • COLLAR | 1 | SN: 10001-(1369) KIT-FLAG: _- SERIALNO: 10001-(1369) |
|||
| ? | 424-15-15421 | • • VALVE | 1 | SN: (1370)- KIT-FLAG: _- SERIALNO: (1370)- |
|||
| ? | 424-15-15420 | • • VALVE | 1 | SN: 10001-(1369) KIT-FLAG: _- SERIALNO: 10001-(1369) |
|||
| ? | 424-15-16420 | • • SHIM, 0.5MM | 2 | SN: 10001-(1369) KIT-FLAG: _- SERIALNO: 10001-(1369) |
|||
| ? | 424-15-16230 | • • SPRING, (L=135.9) | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 424-15-15760 | • • PLUG | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 07002-03034 | • • O-RING (K3) | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 424-15-15470 | • • STOPPER | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 700-80-63230 | • • SPRING | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 04260-01270 | • • BALL | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 424-15-15460 | • • VALVE | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 425-15-15980 | • • COVER | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 07042-20108 | • • PLUG | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 425-15-15961 | • • GASKET (K3) | 1 | SN: (3222)- KIT-FLAG: _- SERIALNO: (3222)- |
|||
| ? | □425-15-15960 | • • GASKET (K3) | 1 | SN: 10001-(3221) KIT-FLAG: _- SERIALNO: 10001-(3221) |
|||
| ? | 01010-50830 | • • BOLT | 8 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 01643-30823 | • • WASHER | 8 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 424-15-15910 | • • COVER | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 424-15-15921 | • • GASKET (K3) | 1 | SN: (3222)- KIT-FLAG: _- SERIALNO: (3222)- |
|||
| ? | □424-15-15920 | • • GASKET (K3) | 1 | SN: 10001-(3221) KIT-FLAG: _- SERIALNO: 10001-(3221) |
|||
| ? | 01010-50830 | • • BOLT | 4 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 01643-30823 | • • WASHER | 4 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 426-15-16510 | • • FILTER ASS'Y | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 209-38-12470 | • • • ELEMENT | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 209-38-12480 | • • • O-RING | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 209-38-12490 | • • • RING,BACK-UP | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 07000-72014 | • • O-RING (K3) | 2 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 01010-51035 | • • BOLT | 2 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 01602-21030 | • • WASHER,SPRING | 2 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 01641-21016 | • • WASHER | 2 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 424-15-15993 | • • GASKET (K3) | 1 | SN: (3222)- KIT-FLAG: _- SERIALNO: (3222)- |
|||
| ? | □424-15-15992 | • • GASKET (K3) | 1 | SN: 10001-(3221) KIT-FLAG: _- SERIALNO: 10001-(3221) |
|||
| ? | (☒425-15-15990) | • • GASKET (K3) | 1 | SN: (10001-(1949)) KIT-FLAG: _- SERIALNO: (10001-(1949)) |
|||
| ? | 425-15-15130 | • • SEAT,VALVE | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 07042-00211 | • • PLUG | 3 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 01010-51040 | • • BOLT | 2 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 01643-31032 | • • WASHER | 2 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
