| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO. | SERIALNO: |
|||||
| ? | (426-15-00011) | TRANSMISSION ASS'Y | 1 | SN: (3001)- KIT-FLAG: _- SERIALNO: (3001)- |
|||
| ? | (426-15-00020) | TRANSMISSION ASS'Y | 1 | SN: (1973)-(3000) KIT-FLAG: _- SERIALNO: (1973)-(3000) |
|||
| ? | (426-15-00010) | TRANSMISSION ASS'Y | 1 | SN: 10001-(1972) KIT-FLAG: _- SERIALNO: 10001-(1972) |
|||
| ? | THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.2501 TO 2534. | SERIALNO: |
|||||
| ? | 426-15-12121 | • SHAFT | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 426-15-12920 | • BUSHING | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 426-15-11560 | • COVER | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 01010-50820 | • BOLT | 3 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 01602-20825 | • WASHER,SPRING | 3 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 426-15-11550 | • COLLAR | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 04064-08530 | • RING,SNAP | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 426-15-12340 | • CARRIER | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 07018-11405 | • RING,SEAL | 2 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 426-15-12430 | • GEAR | 4 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 426-15-12960 | • BEARING | 4 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 426-15-19440 | • WASHER | 8 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 426-15-00160 | • SHAFT ASS'Y | 4 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | ☆ | • • SHAFT | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 145-14-11320 | • • PLUG | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 04025-00624 | • PIN,SPRING | 4 | SN: (1898)- KIT-FLAG: _- SERIALNO: (1898)- |
|||
| ? | □04025-00620 | • PIN,SPRING | 4 | SN: 10001-(1897) KIT-FLAG: _- SERIALNO: 10001-(1897) |
|||
| ? | 426-15-12250 | • GEAR | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 426-15-12860 | • BUSHING | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 06000-06920 | • BEARING | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 04064-01030 | • RING,SNAP | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 04077-00140 | • RING,SNAP | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 04070-00160 | • RING,SNAP | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 426-15-12611 | • GEAR,RING | 1 | SN: (1274)- KIT-FLAG: _- SERIALNO: (1274)- |
|||
| ? | □426-15-12610 | • GEAR,RING | 1 | SN: 10001-(1273) KIT-FLAG: _- SERIALNO: 10001-(1273) |
|||
| ? | 198-15-22810 | • DISC | 3 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 426-15-12720 | • PLATE | 2 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 175-15-42880 | • SPRING | 18 | SN: (1973)- KIT-FLAG: _- SERIALNO: (1973)- |
|||
| ? | □425-15-12880 | • SPRING | 18 | SN: 10001-(1972) KIT-FLAG: _- SERIALNO: 10001-(1972) |
|||
| ? | 234-15-15230 | • SPRING, (L= 52.0) | 12 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 426-15-12750 | • PISTON | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 426-15-19220 | • RING,SEAL (K2) | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 426-15-11130 | • HOUSING | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 155-15-12770 | • PIN | 6 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 426-15-19210 | • RING,SEAL (K2) | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
