| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO. | SERIALNO: |
|||||
| ? | (426-15-00011) | TRANSMISSION ASS'Y | 1 | SN: (3001)- KIT-FLAG: _- SERIALNO: (3001)- |
|||
| ? | (426-15-00020) | TRANSMISSION ASS'Y | 1 | SN: (1973)-(3000) KIT-FLAG: _- SERIALNO: (1973)-(3000) |
|||
| ? | (426-15-00010) | TRANSMISSION ASS'Y | 1 | SN: 10001-(1972) KIT-FLAG: _- SERIALNO: 10001-(1972) |
|||
| ? | THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.2501 TO 2534. | SERIALNO: |
|||||
| ? | 426-15-12330 | • CARRIER | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 426-15-12430 | • GEAR | 4 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 426-15-12960 | • BEARING | 4 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 09233-13220 | • WASHER,THRUST | 8 | SN: (1855)- KIT-FLAG: _- SERIALNO: (1855)- |
|||
| ? | □235-15-12570 | • WASHER,THRUST | 8 | SN: 10001-(1854) KIT-FLAG: _- SERIALNO: 10001-(1854) |
|||
| ? | 426-15-00150 | • SHAFT ASS'Y | 4 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | ☆ | • • SHAFT | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 07043-50108 | • • PLUG | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 04025-00624 | • PIN,SPRING | 4 | SN: (1973)- KIT-FLAG: _- SERIALNO: (1973)- |
|||
| ? | 04025-00620 | • PIN,SPRING | 4 | SN: 10001-(1972) KIT-FLAG: _- SERIALNO: 10001-(1972) |
|||
| ? | 426-15-12240 | • GEAR | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 04064-09530 | • RING,SNAP | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 426-15-12620 | • GEAR,RING | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 426-15-11140 | • HOUSING | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 04020-01434 | • PIN,DOWEL | 14 | SN: (3470)- KIT-FLAG: _- SERIALNO: (3470)- |
|||
| ? | 04020-01434 | • PIN,DOWEL | 12 | SN: 10001-(3469) KIT-FLAG: _- SERIALNO: 10001-(3469) |
|||
| ? | 426-15-19210 | • RING,SEAL (K2) | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 426-15-12740 | • PISTON | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 175-15-59250 | • RING,SEAL (K2) | 1 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 198-15-22810 | • DISC | 3 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 426-15-12720 | • PLATE | 2 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 175-15-42880 | • SPRING | 18 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
|||
| ? | 234-15-15230 | • SPRING, (L= 52.0) | 12 | SN: 10001- KIT-FLAG: _- SERIALNO: 10001- |
