| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 426-03-21920 | BRACKET | 1 | SN: 52001- |
|||
| ? | 01010-81225 | BOLT | 4 | SN: 52001- |
|||
| ? | 01643-31232 | WASHER | 4 | SN: 52001- |
|||
| ? | 426-03-21911 | TANK,GLAY | 1 | SN: 52004- |
|||
| ? | 426-03-21910 | TANK | 1 | SN: 52001-52003 |
|||
| ? | 01010-81225 | BOLT | 4 | SN: 52001- |
|||
| ? | 01643-31232 | WASHER | 4 | SN: 52001- |
|||
| ? | 582-01-12910 | NIPPLE | 2 | SN: 52001- |
|||
| ? | 208-04-19130 | ELBOW | 2 | SN: 52001- |
|||
| ? | 208-04-19160 | BALL,FLOAT | 1 | SN: 52001- |
|||
| ? | 569-03-61940 | TUBE | 1 | SN: 52001- |
|||
| ? | 07053-10000 | CAP | 1 | SN: 52001- |
|||
| ? | 426-03-21930 | HOSE | 1 | SN: 52001- |
|||
| ? | 07281-10137 | CLAMP | 6 | SN: 52001- |
|||
| ? | 426-Z84-3870 | JOINT | 1 | SN: 52001- |
|||
| ? | 426-Z84-3841 | COVER | 1 | SN: 52001- |
|||
| ? | 01435-01020 | BOLT | 4 | SN: 52001- |
|||
| ? | 01643-31032 | WASHER | 4 | SN: 52001- |
|||
| ? | 08034-20536 | BAND | 5 | SN: 52001- |
|||
| ? | 07030-00252 | BREATHER | 1 | SN: 52001- |
|||
| ? | 07730-50004 | VALVE | 1 | SN: 52001- |
|||
| ? | 07261-21413 | HOSE | 1 | SN: 52001- |
|||
| ? | 08037-02512 | GROMMET | 1 | SN: 52001- |
|||
| ? | 07281-00259 | CLAMP | 1 | SN: 52001- |
|||
| ? | 04434-52511 | CLIP | 2 | SN: 52001- |
|||
| ? | 01435-01016 | BOLT | 2 | SN: 52001- |
