| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (426-03-21712) | RADIATOR ASS'Y | 1 | SN: 52010- |
|||
| ? | (426-03-21711) | RADIATOR ASS'Y | 1 | SN: 52001-52009 |
|||
| ? | THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.C0110 -01A0A AND FIGS. C0110-02A0A. | ||||||
| ? | 426-03-21721 | • AFTER COOLER | 1 | SN: 52001- |
|||
| ? | 426-03-21650 | • PLATE | 2 | SN: 52001- |
|||
| ? | 01436-01020 | • BOLT | 8 | SN: 52001- |
|||
| ? | 426-03-21660 | • RUBBER | 2 | SN: 52001- |
|||
| ? | 01010-81225 | • BOLT | 4 | SN: 52001- |
|||
| ? | 01643-31232 | • WASHER | 4 | SN: 52001- |
|||
| ? | 426-03-21670 | • BRACKET,L.H. | 1 | SN: 52001- |
|||
| ? | 426-03-21680 | • BRACKET,R.H. | 1 | SN: 52001- |
|||
| ? | 01010-81235 | • BOLT | 4 | SN: 52001- |
|||
| ? | 01643-31232 | • WASHER | 4 | SN: 52001- |
|||
| ? | 426-03-21730 | • PACKING | 4 | SN: 52001- |
|||
| ? | 426-03-21740 | • PACKING | 4 | SN: 52001- |
|||
| ? | 426-03-21410 | • BRACKET | 1 | SN: 52001- |
|||
| ? | 01010-81225 | • BOLT | 12 | SN: 52001- |
|||
| ? | 01435-01020 | • BOLT | 4 | SN: 52001- |
|||
| ? | 01010-81235 | • BOLT | 4 | SN: 52001- |
|||
| ? | 426-03-21750 | • WASHER | 4 | SN: 52001- |
|||
| ? | 175-03-42140 | • RUBBER | 8 | SN: 52001- |
|||
| ? | 01643-31232 | • WASHER | 4 | SN: 52001- |
|||
| ? | 01643-31232 | • WASHER | 12 | SN: 52001- |
