| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 424-23-20052 | AXLE ASS'Y,REAR | 1 | SN: 63001- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F4500-01A1 TO F4500-04A1. | ||||||
| ? | 421-33-11650 | • GUIDE | 16 | SN: 63001- |
|||
| ? | 421-33-11630 | • SPRING | 16 | SN: 63001- |
|||
| ? | 04020-00514 | • PIN,DOWEL | 16 | SN: 63001- |
|||
| ? | ☆ | • PISTON | 2 | SN: 63001- |
|||
| ? | 421-33-11440 | • SEAL,PISTON | 2 | SN: 63001- |
|||
| ? | 421-33-11480 | • SEAL,PISTON | 2 | SN: 63001- |
|||
| ? | ☆ | • CYLINDER,L.H. | 1 | SN: 63001- |
|||
| ? | ☆ | • CYLINDER,R.H. | 1 | SN: 63001- |
|||
| ? | 566-32-11620 | • CAP | 2 | SN: 63001- |
|||
| ? | 566-32-11430 | • BLEEDER | 2 | SN: 63001- |
|||
| ? | 581-32-12140 | • PLUG | 2 | SN: 63001- |
|||
| ? | 07040-12012 | • PLUG,(FOR SHIPPING) | 2 | SN: 63001- |
|||
| ? | 07002-12034 | • O-RING,(FOR SHIPPING) | 2 | SN: 63001- |
|||
| ? | ☆ | • HUB | 2 | SN: 63001- |
|||
| ? | 01144-62070 | • STUD | 50 | SN: 63001- |
|||
| ? | 235-25-11360 | • DISC | 10 | SN: 63001- |
|||
| ? | 232-25-51430 | • PLATE | 12 | SN: 63001- |
|||
| ? | 421-33-11280 | • PLATE | 2 | SN: 63001- |
|||
| ? | 07000-13028 | • O-RING | 16 | SN: 63001- |
|||
| ? | 07000-15445 | • O-RING | 2 | SN: 63001- |
|||
| ? | 07040-11409 | • PLUG | 4 | SN: 63001- |
|||
| ? | 07002-11423 | • O-RING | 4 | SN: 63001- |
|||
| ? | 07000-12016 | • O-RING | 2 | SN: 63001- |
|||
| ? | 421-33-21230 | • GEAR | 2 | SN: 63001- |
|||
| ? | 01010-31440 | • BOLT | 28 | SN: 63001- |
|||
| ? | 01643-31445 | • WASHER | 28 | SN: 63001- |
|||
| ? | 421-33-11330 | • GEAR | 2 | SN: 63001- |
|||
| ? | 01010-31670 | • BOLT | 32 | SN: 63001- |
|||
| ? | 01643-31645 | • WASHER | 32 | SN: 63001- |
|||
| ? | 423-33-00020 | • FLOATING SEAL ASS'Y | 2 | SN: 63001- |
|||
| ? | ☆ | • • RING | 2 | SN: 63001- |
|||
| ? | ☆ | • • O-RING | 2 | SN: 63001- |
|||
| ? | 421-33-21811 | • SEAL | 2 | SN: 63001- |
