| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (714-17-10000) | TRANSMISSION ASS'Y | 1 | SN: 63001- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-68A0. | ||||||
| ? | 714-07-12142 | • SHAFT,PTO | 1 | SN: 63001- |
|||
| ? | 714-07-12152 | • COLLAR,INPUT | 1 | SN: 63001- |
|||
| ? | 06040-06208 | • BEARING | 1 | SN: 63001- |
|||
| ? | 04065-08025 | • RING,SNAP | 1 | SN: 63001- |
|||
| ? | 04064-04018 | • RING,SNAP | 1 | SN: 63001- |
|||
| ? | 04065-01910 | • RING,SNAP | 1 | SN: 63001- |
|||
| ? | 714-07-14310 | • GEAR¤ 76 TEETH,IDLER | 1 | SN: 63001- |
|||
| ? | 714-07-12330 | • BEARING | 1 | SN: 63001- |
|||
| ? | 714-07-14320 | • SPACER | 1 | SN: 63001- |
|||
| ? | 04065-01254 | • RING,SNAP | 1 | SN: 63001- |
|||
| ? | 714-07-14330 | • HUB,SPLINE | 1 | SN: 63001- |
|||
| ? | 01530-06214 | • NUT | 1 | SN: 63001- |
|||
| ? | 714-07-14340 | • SHAFT,IDLER | 1 | SN: 63001- |
|||
| ? | 07000-02055 | • O-RING (K1) | 1 | SN: 63001- |
|||
| ? | 01010-81235 | • BOLT | 2 | SN: 63001- |
|||
| ? | 01643-31232 | • WASHER | 2 | SN: 63001- |
|||
| ? | 714-07-14410 | • SHAFT | 2 | SN: 63001- |
|||
| ? | 714-07-12340 | • BEARING | 2 | SN: 63001- |
|||
| ? | 06040-06213 | • BEARING | 2 | SN: 63001- |
|||
| ? | 714-07-13210 | • RING,SNAP | 2 | SN: 63001- |
|||
| ? | 04064-06525 | • RING,SNAP | 2 | SN: 63001- |
|||
| ? | 714-07-14420 | • GEAR¤ 74 TEETH | 1 | SN: 63001- |
|||
| ? | 714-07-14430 | • GEAR¤ 65 TEETH | 1 | SN: 63001- |
|||
| ? | 714-07-14450 | • RING | 2 | SN: 63001- |
|||
| ? | 714-07-14461 | • SPACER | 4 | SN: 63001- |
|||
| ? | 04065-01204 | • RING,SNAP | 2 | SN: 63001- |
|||
| ? | 04065-09030 | • RING,SNAP | 2 | SN: 63001- |
