| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO. | ||||||
| ? | (714-17-10000) | TRANSMISSION ASS'Y | 1 | SN: 63001- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-68A0. | ||||||
| ? | 714-17-12020 | • CLUTCH ASS'Y,REVERSE AND 2ND | 1 | SN: 63001- |
|||
| ? | 714-17-12120 | • • SHAFT ASS'Y | 1 | SN: 63001- |
|||
| ? | 714-07-12911 | • • PISTON,REVERSE | 1 | SN: 63001- |
|||
| ? | 714-07-12661 | • • PISTON,2ND | 1 | SN: 63001- |
|||
| ? | 714-07-12670 | • • DISC | 6 | SN: 63001- |
|||
| ? | 714-07-19720 | • • DISC | 10 | SN: 63001- |
|||
| ? | 714-07-12680 | • • PLATE,SEPARATE | 18 | SN: 63001- |
|||
| ? | 714-07-12691 | • • SPRING | 10 | SN: .- |
|||
| ? | □714-07-12690 | • • SPRING,WAVE | 10 | SN: 63001-. |
|||
| ? | 714-07-12780 | • • SPRING,WAVE | 6 | SN: 63001- |
|||
| ? | 714-07-12711 | • • PLATE,END | 2 | SN: 63001- |
|||
| ? | 714-07-12720 | • • RING,SNAP | 2 | SN: 63001- |
|||
| ? | 714-07-19320 | • • RING,SEAL | 2 | SN: 63001- |
|||
| ? | 714-08-19220 | • • RING,SEAL | 1 | SN: 63001- |
|||
| ? | 714-07-12740 | • • RING,SEAL | 1 | SN: 63001- |
|||
| ? | 714-07-12220 | • • WASHER,THRUST | 4 | SN: 63001- |
|||
| ? | 714-07-12920 | • • WASHER,THRUST | 1 | SN: 63001- |
|||
| ? | 714-07-12250 | • • SPACER | 2 | SN: 63001- |
|||
| ? | 714-07-12281 | • • BEARING,NEEDLE | 4 | SN: (101190)- |
|||
| ? | □714-07-12280 | • • BEARING,NEEDLE | 4 | SN: 63001-(101189) |
|||
| ? | 714-17-12420 | • • GEAR¤ 47 TEETH,REVERSE | 1 | SN: 63001- |
|||
| ? | 714-07-13151 | • • GEAR¤ 26-50 TEETH,2ND | 1 | SN: 63001- |
|||
| ? | 06040-06315 | • • BEARING | 1 | SN: 63001- |
|||
| ? | 714-07-19340 | • • BEARING,ROLLER | 1 | SN: 63001- |
|||
| ? | 714-07-12290 | • RING,SEAL | 3 | SN: 63001- |
