| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (709-94-11700) | CONTROL VALVE | 1 | SN: 63001- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1664-01A0 T0 Y1664-04A0. | ||||||
| ? | 709-91-00080 | • VALVE SUB ASS'Y | 1 | SN: 63001- |
|||
| ? | ☆ | • • COVER,VALVE | 1 | SN: 63001- |
|||
| ? | ☆ | • • PLUG | 1 | SN: 63001- |
|||
| ? | ☆ | • • VALVE | 1 | SN: 63001- |
|||
| ? | 702-21-37220 | • • SPRING | 1 | SN: 63001- |
|||
| ? | ☆ | • • PISTON | 1 | SN: 63001- |
|||
| ? | 700-92-11530 | • • FLANGE | 1 | SN: 63001- |
|||
| ? | 07000-13032 | • • O-RING | 1 | SN: 63001- |
|||
| ? | 01010-81035 | • • BOLT | 2 | SN: 63001- |
|||
| ? | 702-21-37251 | • • SCREEN ASS'Y | 1 | SN: 63001- |
|||
| ? | 07002-11423 | • • O-RING | 2 | SN: 63001- |
|||
| ? | 07000-11007 | • • O-RING | 1 | SN: 63001- |
|||
| ? | 706-73-72420 | • • VALVE | 1 | SN: 63001- |
|||
| ? | 706-73-72440 | • • SPRING | 1 | SN: 63001- |
|||
| ? | 01252-30516 | • • BOLT | 4 | SN: 63001- |
|||
| ? | 01643-31032 | • • WASHER | 6 | SN: 63001- |
|||
| ? | 706-77-71670 | • • PLUG | 1 | SN: 63001- |
|||
| ? | 07002-13034 | • • O-RING | 1 | SN: 63001- |
|||
| ? | 702-21-37280 | • • FLANGE | 1 | SN: 63001- |
|||
| ? | 07000-11009 | • • O-RING | 2 | SN: 63001- |
|||
| ? | 708-8H-11530 | • • PLUG | 3 | SN: 63001- |
|||
| ? | 01010-81030 | • • BOLT | 4 | SN: 63001- |
|||
| ? | 709-63-11340 | • • BAR | 1 | SN: 63001- |
|||
| ? | 700-92-11540 | • • SEAT | 1 | SN: 63001- |
|||
| ? | 07000-12018 | • • O-RING | 1 | SN: 63001- |
|||
| ? | 07002-11423 | • • O-RING | 2 | SN: 63001- |
|||
| ? | 708-25-15370 | • • WASHER | 4 | SN: 63001- |
|||
| ? | 700-85-11121 | • BOLT | 2 | SN: 63001- |
|||
| ? | 700-92-11810 | • BOLT | 2 | SN: 63001- |
|||
| ? | 01643-31232 | • WASHER | 4 | SN: 63001- |
