| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 705-52-30390 | PUMP ASS'Y,(SAR100+28) | 1 | SN: 63001- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1610-31A0 AND Y1610-32A0. | ||||||
| ? | 705-22-40090 | • PUMP ASS'Y,(SAR100) | 1 | SN: 63001- |
|||
| ? | (★705-18-03620) | • • BRACKET ASS'Y | 1 | SN: 63001- |
|||
| ? | (★705-18-03350) | • • • BUSHING,PLANE | 2 | SN: 63001- |
|||
| ? | (★705-17-40010) | • • CASE,GEAR | 1 | SN: 63001- |
|||
| ? | (★705-18-03240) | • • CARRIER | 1 | SN: 63001- |
|||
| ? | (★705-18-03350) | • • • BUSHING,PLANE | 2 | SN: 63001- |
|||
| ? | (★705-19-40630) | • • GEAR,DRIVE | 1 | SN: 63001- |
|||
| ? | (★705-17-40810) | • • GEAR,DRIVEN | 1 | SN: 63001- |
|||
| ? | 705-17-03610 | • • PLATE,SIDE | 2 | SN: 63001- |
|||
| ? | 705-17-03473 | • • SEAL | 2 | SN: 63001- |
|||
| ? | 705-17-03443 | • • RING,BACK-UP | 2 | SN: 63001- |
|||
| ? | 705-17-03381 | • • O-RING | 2 | SN: 63001- |
|||
| ? | 04020-01228 | • • PIN,DOWEL | 4 | SN: 63001- |
|||
| ? | 705-17-03770 | • • BOLT | 4 | SN: 63001- |
|||
| ? | 01643-51645 | • • WASHER | 4 | SN: 63001- |
|||
| ? | 705-17-03870 | • • PLATE | 1 | SN: 63001- |
|||
| ? | 705-17-03811 | • • SEAL,OIL | 1 | SN: 63001- |
|||
| ? | 04065-05220 | • • RING,SNAP | 1 | SN: 63001- |
