| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 424-877-2610 | LIFT ARM ASS'Y (REWORK) | 1 | SN: 63001- |
|||
| ? | ☆ | • ARM,LIFT | 1 | SN: 63001- |
|||
| ? | 01573-22306 | • SEAT (WELDED) | 4 | SN: 63001- |
|||
| ? | 423-70-21810 | BUSHING | 2 | SN: 63001- |
|||
| ? | 424-70-11770 | BUSHING | 2 | SN: 63001- |
|||
| ? | 424-70-11890 | BUSHING | 2 | SN: 63001- |
|||
| ? | 424-09-12320 | • SEAL,DUST | 4 | SN: 63001- |
|||
| ? | 421-09-11310 | • SEAL,DUST | 8 | SN: 63001- |
|||
| ? | 07020-00000 | • FITTING,GREASE | 2 | SN: 63001- |
|||
| ? | 424-70-21200 | BELLCRANK ASS'Y | 1 | SN: 63001- |
|||
| ? | ☆ | • BELLCRANK | 1 | SN: 63001- |
|||
| ? | 424-70-11860 | • BUSHING | 1 | SN: 63001- |
|||
| ? | 421-09-11350 | • SEAL,DUST | 2 | SN: 63001- |
|||
| ? | 07020-00900 | • FITTING,GREASE | 1 | SN: 63001- |
|||
| ? | 423-70-21300 | LINK ASS'Y | 1 | SN: 63001- |
|||
| ? | 423-70-21140 | • LINK | 1 | SN: 63001- |
|||
| ? | 424-70-11820 | • BUSHING | 2 | SN: 63001- |
|||
| ? | 424-09-12320 | • SEAL,DUST | 4 | SN: 63001- |
|||
| ? | 07020-00000 | • FITTING,GREASE | 2 | SN: 63001- |
