| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO. | ||||||
| ? | (714-07-10050) | TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING) | 1 | SN: 53001-54000 |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-69A0. | ||||||
| ? | (714-07-15400) | • VALVE ASS'Y,FLOW CONTROL | 1 | SN: 53001-@ |
|||
| ? | 07230-20628 | • UNION | 1 | SN: 53001-@ |
|||
| ? | 07002-02434 | • O-RING (K3) | 1 | SN: 53001-@ |
|||
| ? | 01252-31065 | • BOLT | 1 | SN: 53001-@ |
|||
| ? | 01252-31055 | • BOLT | 3 | SN: 53001-@ |
|||
| ? | 07000-72020 | • O-RING (K2) | 1 | SN: 53001-@ |
|||
| ? | (714-07-17600) | • VALVE ASS'Y,ACCUMULATOR | 1 | SN: 53001-54000 |
|||
| ? | 01010-81085 | • BOLT | 3 | SN: 53001-@ |
|||
| ? | 07000-72014 | • O-RING (K2) | 1 | SN: 53001-@ |
|||
| ? | 07000-72020 | • O-RING (K2) | 6 | SN: 53001-@ |
|||
| ? | (714-07-17014) | • VALVE ASS'Y,TRANSMISSION | 1 | SN: (106844)-(107071) |
|||
| ? | (□714-07-17013) | • VALVE ASS'Y,TRANSMISSION | 1 | SN: 53001-(106843) |
|||
| ? | 714-07-16670 | • BOLT | 8 | SN: 53001-54000 |
|||
| ? | 08053-01510 | • CLIP | 1 | SN: 53001-@ |
|||
| ? | 01011-81020 | • BOLT | 1 | SN: 53001-@ |
|||
| ? | 01011-81040 | • BOLT | 2 | SN: 53001-54000 |
|||
| ? | 01011-81015 | • BOLT | 2 | SN: 53001-@ |
|||
| ? | 01010-81085 | • BOLT | 2 | SN: 53001-@ |
|||
| ? | 01643-31032 | • WASHER | 1 | SN: 53001-@ |
|||
| ? | 714-07-16921 | • GASKET,LOWER VALVE (K2) | 1 | SN: (106612)-@ |
|||
| ? | □714-07-16920 | • GASKET,LOWER VALVE (K2) | 1 | SN: 53001-(106611) |
|||
| ? | (714-07-17703) | • VALVE ASS'Y,MODULATION | 1 | SN: (106612)-(107071) |
|||
| ? | (714-07-17701) | • VALVE ASS'Y,MODULATION | 1 | SN: 53001-(106611) |
|||
| ? | 714-07-17791 | • GASKET (K2) | 1 | SN: (106612)-(107071) |
|||
| ? | □714-07-17790 | • GASKET (K2) | 1 | SN: 53001-(106611) |
|||
| ? | 01010-81065 | • BOLT | 5 | SN: (106612)-(107071) |
|||
| ? | 01010-81050 | • BOLT | 5 | SN: 53001-(106611) |
|||
| ? | 01010-81065 | • BOLT | 1 | SN: 53001-54000 |
