| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO. | ||||||
| ? | (714-07-10041) | TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING) | 1 | SN: 54001- |
|||
| ? | (714-07-10050) | TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING) | 1 | SN: 53001-54000 |
|||
| ? | THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-69A0. | ||||||
| ? | 714-07-13500 | • CLUTCH ASS'Y,3RD AND 4TH | 1 | SN: 53001- |
|||
| ? | 714-07-13511 | • • SHAFT ASS'Y | 1 | SN: 53001- |
|||
| ? | 714-07-12661 | • • PISTON | 2 | SN: 53001- |
|||
| ? | 714-07-12670 | • • DISC | 12 | SN: 53001- |
|||
| ? | 714-07-12680 | • • PLATE,SEPARATE | 14 | SN: 53001- |
|||
| ? | 714-07-12780 | • • SPRING,WAVE | 12 | SN: 53001- |
|||
| ? | 714-07-12711 | • • PLATE,END | 2 | SN: 53001- |
|||
| ? | 714-07-12720 | • • RING,SEAL | 2 | SN: 53001- |
|||
| ? | 714-07-19320 | • • RING,SEAL | 2 | SN: 53001- |
|||
| ? | 714-07-12740 | • • RING,SEAL | 2 | SN: 53001- |
|||
| ? | 714-07-12220 | • • WASHER,THRUST | 2 | SN: 53001- |
|||
| ? | 714-07-12210 | • • WASHER,THRUST | 2 | SN: 53001- |
|||
| ? | 714-07-12930 | • • WASHER,THRUST | 1 | SN: 53001- |
|||
| ? | 714-07-12250 | • • SPACER | 2 | SN: 53001- |
|||
| ? | 56B-15-19410 | • • BEARING,NEEDLE | 2 | SN: 55085- |
|||
| ? | 714-07-12271 | • • BEARING,NEEDLE | 2 | SN: (106986)-(107853) |
|||
| ? | □714-07-12270 | • • BEARING,NEEDLE | 2 | SN: 53001-(106985) |
|||
| ? | 56B-15-19420 | • • BEARING,NEEDLE | 2 | SN: 55085- |
|||
| ? | 714-07-12281 | • • BEARING,NEEDLE | 2 | SN: (106986)-(107853) |
|||
| ? | □714-07-12280 | • • BEARING,NEEDLE | 2 | SN: 53001-(106985) |
|||
| ? | 714-07-13620 | • • GEAR¤ 53 TEETH,4TH | 1 | SN: 53001- |
|||
| ? | 714-07-13541 | • • GEAR¤ 43-49 TEETH,3RD | 1 | SN: 53001- |
|||
| ? | 06040-06215 | • • BEARING | 1 | SN: 53001- |
|||
| ? | 714-07-19340 | • • BEARING | 1 | SN: 53001- |
|||
| ? | 714-07-12290 | • RING,SEAL | 3 | SN: 53001- |
