| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 421-Z94-2530 | WIRING HARNESS | 2 | SN: 53001- |
|||
| ? | 01643-31232 | WASHER | 6 | SN: 53001- |
|||
| ? | 08037-03614 | GROMMET | 2 | SN: 53001- |
|||
| ? | 421-Z94-2510 | BRACKET | 1 | SN: 53001- |
|||
| ? | 01010-81025 | BOLT | 2 | SN: 53001- |
|||
| ? | 01643-31032 | WASHER | 2 | SN: 53001- |
|||
| ? | 421-Z94-2520 | BRACKET | 1 | SN: 53001- |
|||
| ? | 01010-81025 | BOLT | 2 | SN: 53001- |
|||
| ? | 01643-31032 | WASHER | 2 | SN: 53001- |
|||
| ? | 417-54-13470 | SPACER | 6 | SN: 53001- |
|||
| ? | 419-43-17930 | CUSHION | 6 | SN: 53001- |
|||
| ? | 415-64-13130 | CUSHION | 6 | SN: 53001- |
|||
| ? | 419-43-17920 | WASHER | 6 | SN: 53001- |
|||
| ? | 01435-01250 | BOLT | 6 | SN: 53001- |
|||
| ? | 08037-03614 | GROMMET | 2 | SN: 53001- |
|||
| ? | 417-06-23212 | HEAD LAMP ASS'Y | 2 | SN: 53001- |
|||
| ? | 417-06-23221 | • BULB¤ 62/62W | 1 | SN: 53001- |
|||
| ? | 417-06-23260 | • LENS | 1 | SN: 53001- |
|||
| ? | 41G-06-13201 | LAMP ASS'Y | 2 | SN: 53001- |
|||
| ? | 41G-06-13210 | • LENS,FRONT | 1 | SN: 53001- |
|||
| ? | 41G-06-13220 | • LENS,REAR | 1 | SN: 53001- |
|||
| ? | 41G-06-13230 | • BULB¤ 5W | 1 | SN: 53001- |
|||
| ? | 08105-12420 | • BULB¤ 25W | 1 | SN: 53001- |
|||
| ? | 01220-40425 | • SCREW | 4 | SN: 53001- |
|||
| ? | 421-06-23611 | COVER | 1 | SN: 53001- |
|||
| ? | 421-06-23621 | COVER | 1 | SN: 53001- |
|||
| ? | 01220-40616 | SCREW | 10 | SN: 53001- |
|||
| ? | 01643-30623 | WASHER | 10 | SN: 53001- |
|||
| ? | 423-Z94-2160 | BRACKET | 1 | SN: 53001- |
|||
| ? | 423-Z94-2150 | BRACKET | 1 | SN: 53001- |
|||
| ? | 01010-51225 | BOLT | 6 | SN: 53001- |
|||
| ? | 421-Z94-2190 | SUPPORT,L.H. | 1 | SN: 53001- |
|||
| ? | 421-Z94-2210 | SUPPORT,R.H. | 1 | SN: 53001- |
