| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 424-23-20001 | AXLE ASS'Y,REAR | 1 | SN: 60001- |
|||
| ? | (☒424-23-20000) | AXLE ASS'Y,REAR | 1 | SN: (60001-.) |
|||
| ? | THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.3201 TO 3231. | ||||||
| ? | 424-23-23120 | • HOUSING | 1 | SN: 60001- |
|||
| ? | 07044-13620 | • PLUG,DRAIN | 1 | SN: 60001- |
|||
| ? | 07041-13612 | • PLUG | 2 | SN: 60001- |
|||
| ? | 07002-13634 | • O-RING | 3 | SN: 60001- |
|||
| ? | 07030-01030 | • BREATHER | 1 | SN: 60001- |
|||
| ? | 421-22-13230 | • SHAFT | 2 | SN: 60001- |
|||
| ? | 07040-11007 | • PLUG | 4 | SN: 60001- |
|||
| ? | 07002-11023 | • O-RING | 4 | SN: 60001- |
|||
| ? | 07000-15220 | • O-RING | 2 | SN: 60001- |
|||
| ? | 01252-31040 | • BOLT | 6 | SN: 60001- |
|||
| ? | 01010-62495 | • BOLT | 32 | SN: 60001- |
|||
| ? | 01643-32460 | • WASHER | 32 | SN: 60001- |
|||
| ? | (424-23-21001) | • DIFFERENTIAL ASS'Y,REAR | 1 | SN: 60001- |
|||
| ? | (☒424-23-21000) | • DIFFERENTIAL ASS'Y,REAR | 1 | SN: (60001-.) |
|||
| ? | 04020-01638 | • PIN,DOWEL | 1 | SN: 60001- |
|||
| ? | 07000-15455 | • O-RING | 1 | SN: 60001- |
|||
| ? | 424-23-23290 | • PLATE | 1 | SN: 60001- |
|||
| ? | 01010-61450 | • BOLT | 18 | SN: 60001- |
|||
| ? | 01010-61455 | • BOLT | 2 | SN: 60001- |
|||
| ? | 01643-31445 | • WASHER | 20 | SN: 60001- |
|||
| ? | 421-23-23310 | • SUPPORT | 1 | SN: 60001- |
|||
| ? | 04020-01842 | • PIN,DOWEL | 2 | SN: 60001- |
|||
| ? | 01010-61445 | • BOLT | 14 | SN: 60001- |
|||
| ? | 01643-31445 | • WASHER | 14 | SN: 60001- |
|||
| ? | ☆ | • PLATE¤ NAME,(LIMITED SUPPLY) | 1 | SN: 60001- |
|||
| ? | 04418-13060 | • SCREW | 4 | SN: 60001- |
