| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (418-23-30001) | AXLE ASS'Y,REAR | 1 | SN: 70001- |
|||
| ? | (418-23-30050) | AXLE ASS'Y,REAR (ASD) | 1 | SN: 70001- |
|||
| ? | THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.F4500-01A0 TO F4500-04A0. | ||||||
| ? | 07044-13620 | • PLUG | 1 | SN: 70001- |
|||
| ? | 07002-13634 | • O-RING | 1 | SN: 70001- |
|||
| ? | 07043-70211 | • PLUG | 2 | SN: 70001- |
|||
| ? | 419-33-11460 | • BLEEDER | 2 | SN: 70001- |
|||
| ? | 566-32-11620 | • CAP | 2 | SN: 70001- |
|||
| ? | 07041-13612 | • PLUG | 2 | SN: 70001- |
|||
| ? | 07002-13634 | • O-RING | 2 | SN: 70001- |
|||
| ? | 418-23-33120 | • COVER | 1 | SN: 70001- |
|||
| ? | 04020-01228 | • PIN,DOWEL | 2 | SN: 70001- |
|||
| ? | 01010-61230 | • BOLT | 16 | SN: 70001- |
|||
| ? | 01643-31232 | • WASHER | 16 | SN: 70001- |
|||
| ? | 418-22-31162 | • CARRIER | 2 | SN: 70001- |
|||
| ? | 418-22-31710 | • SHIM¤ 0.05MM | 6 | SN: 70001- |
|||
| ? | 418-22-31720 | • SHIM¤ 0.2MM | 4 | SN: 70001- |
|||
| ? | 418-22-31730 | • SHIM¤ 0.3MM | 4 | SN: 70001- |
|||
| ? | 418-22-31740 | • SHIM¤ 0.8MM | 2 | SN: 70001- |
|||
| ? | 418-33-21430 | • RING | 2 | SN: 70001- |
|||
| ? | 01010-61230 | • BOLT | 16 | SN: 70001- |
|||
| ? | 01643-51232 | • WASHER | 16 | SN: 70001- |
|||
| ? | 418-33-31440 | • SEAL | 2 | SN: 70001- |
|||
| ? | 418-33-31360 | • PLATE | 2 | SN: 70001- |
|||
| ? | 418-33-31261 | • DISK | 4 | SN: 70001- |
|||
| ? | 418-33-31121 | • PISTON | 2 | SN: 70001- |
|||
| ? | 418-33-31410 | • SEAL | 2 | SN: 70001- |
|||
| ? | 418-33-31250 | • PLATE | 2 | SN: 70001- |
|||
| ? | 418-33-31610 | • SPRING | 8 | SN: 70001- |
|||
| ? | 01252-60816 | • BOLT | 4 | SN: 70001- |
|||
| ? | 154-61-16570 | • WASHER | 4 | SN: 70001- |
