| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (418-17-31000) | TRANSFER ASS'Y | 1 | SN: 70001- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F2420-51A0 TO F2420-54A0. | ||||||
| ? | 418-17-32211 | • GEAR | 1 | SN: 70001- |
|||
| ? | 418-17-32411 | • GEAR | 3 | SN: 70001- |
|||
| ? | 418-17-32611 | • GEAR,RING | 1 | SN: 70001- |
|||
| ? | 418-17-32312 | • CARRIER | 1 | SN: 70001- |
|||
| ? | 418-17-32511 | • SHAFT | 3 | SN: 70001- |
|||
| ? | 418-17-39311 | • BEARING,NEEDLE | 3 | SN: 70001- |
|||
| ? | 418-17-32570 | • THRUST WASHER | 6 | SN: 70001- |
|||
| ? | 04260-00635 | • BALL | 3 | SN: 70001- |
|||
| ? | 04020-01228 | • PIN | 2 | SN: 70001- |
|||
| ? | 01252-31260 | • BOLT | 6 | SN: 70001- |
|||
| ? | 418-17-33212 | • GEAR | 1 | SN: 70001- |
|||
| ? | 14Y-22-13270 | • RING | 1 | SN: 70001- |
|||
| ? | 418-17-39321 | • BEARING | 1 | SN: 70001- |
|||
| ? | 418-17-33220 | • GEAR | 1 | SN: 70001- |
|||
| ? | 06040-06011 | • BEARING | 2 | SN: 70001- |
|||
| ? | 04065-09030 | • RING,SNAP | 1 | SN: 70001- |
|||
| ? | 418-17-33231 | • GEAR,OUTPUT | 1 | SN: 70001- |
|||
| ? | 418-17-33411 | • BUFFLE | 1 | SN: 70001- |
|||
| ? | 01010-81225 | • BOLT | 1 | SN: 70001- |
|||
| ? | 01643-31232 | • WASHER | 1 | SN: 70001- |
|||
| ? | 418-17-32122 | • SHAFT | 1 | SN: 70001- |
|||
| ? | 04064-07525 | • RING | 1 | SN: 70001- |
|||
| ? | 417-17-32132 | • SPACER | 1 | SN: 70001- |
|||
| ? | 418-17-39330 | • BEARING | 1 | SN: 70001- |
|||
| ? | 418-17-39340 | • BEARING | 1 | SN: 70001- |
