| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (418-923-2000) | CAB ASS'Y | 1 | SN: 50001- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.5541 TO 5549. | ||||||
| ? | 418-923-1170 | • GLASS,REAR | 1 | SN: 50001- |
|||
| ? | 418-923-1230 | • STRIP,WEATHER | 1 | SN: 50001- |
|||
| ? | 418-923-1180 | • GLASS | 2 | SN: 50001- |
|||
| ? | 418-923-1241 | • STRIP,WEATHER | 2 | SN: 50001- |
|||
| ? | 421-56-21530 | • WIPER MOTOR ASS'Y | 1 | SN: 50001- |
|||
| ? | 01435-00812 | • BOLT | 2 | SN: 50001- |
|||
| ? | 421-56-15321 | • ARM,WIPER | 1 | SN: 50001- |
|||
| ? | 419-923-1290 | • BLADE,WIPER | 1 | SN: 50001- |
|||
| ? | 01220-40516 | • SCREW | 1 | SN: 50001- |
|||
| ? | 01641-20508 | • WASHER | 1 | SN: 50001- |
|||
| ? | 418-923-2230 | • COVER,INSPECTION | 1 | SN: 50001- |
|||
| ? | 01435-00612 | • BOLT | 4 | SN: 50001- |
|||
| ? | 201-06-21420 | • ANTENNA | 1 | SN: 50001- |
|||
| ? | 01220-40425 | • SCREW | 3 | SN: 50001- |
|||
| ? | 418-923-2270 | • CORD | 1 | SN: 50001- |
|||
| ? | 418-923-2240 | • COVER | 1 | SN: 50001- |
|||
| ? | 421-09-21410 | • SCREW | 4 | SN: 50001- |
