| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (714-16-10031) | TRANSMISSION ASS'Y | 1 | SN: (83187)- |
|||
| ? | (□714-16-10030) | TRANSMISSION ASS'Y | 1 | SN: 50001-(83186) |
|||
| ? | THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.2301 TO 2371. | ||||||
| ? | 419-15-14800 | • FILTER ASS'Y | 1 | SN: 50001- |
|||
| ? | 419-15-14820 | • • CASE | 1 | SN: 50001- |
|||
| ? | 07040-11209 | • • PLUG | 1 | SN: 50001- |
|||
| ? | 07002-01223 | • • O-RING (K4) | 1 | SN: 50001- |
|||
| ? | 424-16-11140 | • • ELEMENT | 1 | SN: 50001- |
|||
| ? | 419-15-14840 | • • PLATE | 1 | SN: 50001- |
|||
| ? | 419-15-14870 | • • GASKET (K4) | 1 | SN: 50001- |
|||
| ? | 424-16-11190 | • • SPRING | 1 | SN: 50001- |
|||
| ? | 419-15-14880 | • • COVER ASS'Y | 1 | SN: 50001- |
|||
| ? | ☆ | • • • COVER,HEAD | 1 | SN: 50001- |
|||
| ? | ☆ | • • • VALVE | 1 | SN: 50001- |
|||
| ? | 424-16-11130 | • • O-RING (K4) | 1 | SN: 50001- |
|||
| ? | 419-15-14830 | • • BOLT,CENTER | 1 | SN: 50001- |
|||
| ? | 419-15-14850 | • • WASHER | 1 | SN: 50001- |
|||
| ? | 419-15-14860 | • • O-RING (K4) | 1 | SN: 50001- |
