| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (714-16-10031) | TRANSMISSION ASS'Y | 1 | SN: (83187)- |
|||
| ? | (□714-16-10030) | TRANSMISSION ASS'Y | 1 | SN: 50001-(83186) |
|||
| ? | THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.2301 TO 2371. | ||||||
| ? | 714-07-16920 | • GASKET,LOWER VALVE (K2) | 1 | SN: 50001- |
|||
| ? | 714-07-16670 | • BOLT | 10 | SN: 50001- |
|||
| ? | 01011-81040 | • BOLT | 2 | SN: 50001- |
|||
| ? | 01011-81015 | • BOLT | 2 | SN: 50001- |
|||
| ? | 01010-31085 | • BOLT | 1 | SN: 50001- |
|||
| ? | 426-06-11570 | • BRACKET | 1 | SN: 50001- |
|||
| ? | 01010-81090 | • BOLT | 1 | SN: 50001- |
|||
| ? | 01011-31020 | • BOLT | 1 | SN: 50001- |
|||
| ? | 01643-31032 | • WASHER | 2 | SN: 50001- |
|||
| ? | 714-07-17790 | • GASKET (K2) | 1 | SN: 50001- |
|||
| ? | 01010-61050 | • BOLT | 5 | SN: 50001- |
|||
| ? | 08053-01510 | • CLIP | 1 | SN: 50001- |
|||
| ? | 01010-61070 | • BOLT | 1 | SN: 50001- |
|||
| ? | 01643-31032 | • WASHER | 1 | SN: 50001- |
|||
| ? | 07000-73025 | • O-RING (K2) | 2 | SN: 50001- |
|||
| ? | 07000-72014 | • O-RING (K2) | 2 | SN: 50001- |
|||
| ? | 01010-81080 | • BOLT | 1 | SN: 50001- |
|||
| ? | 01010-81070 | • BOLT | 2 | SN: 50001- |
