| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 419-915-1211 | HOSE | 2 | SN: 50001- |
|||
| ? | 41H-62-13300 | JOINT,SWIVEL | 2 | SN: 50001- |
|||
| ? | 419-915-1251 | BLOCK,L.H. | 1 | SN: 50001- |
|||
| ? | 419-915-1241 | BLOCK,R.H. | 1 | SN: 50001- |
|||
| ? | 01010-31020 | BOLT | 4 | SN: 50001- |
|||
| ? | 01643-31032 | WASHER | 4 | SN: 50001- |
|||
| ? | 419-915-1230 | HOSE | 2 | SN: 50001- |
|||
| ? | 423-915-1310 | JOINT ASS'Y | 2 | SN: 50001- |
|||
| ? | 07230-10628 | UNION | 2 | SN: 50001- |
|||
| ? | 07002-12434 | O-RING | 2 | SN: 50001- |
|||
| ? | 423-915-1210 | TUBE,L.H. | 1 | SN: 50001- |
|||
| ? | 423-915-1230 | TUBE,R.H. | 1 | SN: 50001- |
|||
| ? | 01010-31020 | BOLT | 4 | SN: 50001- |
|||
| ? | 01643-31032 | WASHER | 4 | SN: 50001- |
|||
| ? | 07123-20615 | HOSE | 2 | SN: 50001- |
|||
| ? | 07235-10628 | ELBOW | 2 | SN: 50001- |
|||
| ? | 07002-12434 | O-RING | 2 | SN: 50001- |
|||
| ? | 423-905-1390 | CLAMP | 2 | SN: 50001- |
|||
| ? | 01010-30816 | BOLT | 4 | SN: 50001- |
|||
| ? | 01602-00825 | WASHER,SPRING | 4 | SN: 50001- |
