| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 421-V91-2611 | LEVER ASS'Y,ATTACHMENT | 1 | SN: 50001- |
|||
| ? | (☒421-V91-2610) | LEVER ASS'Y,ATTACHMENT | 1 | SN: (50001-.) |
|||
| ? | 421-V91-2121 | • LEVER | 1 | SN: 50001- |
|||
| ? | (☒421-V91-2120) | • LEVER | 1 | SN: (50001-.) |
|||
| ? | 08056-00050 | • TERMINAL | 2 | SN: 50001- |
|||
| ? | 417-06-21110 | • SWITCH ASS'Y | 1 | SN: 50001- |
|||
| ? | 417-06-21140 | • • COVER,TOP | 1 | SN: 50001- |
|||
| ? | 421-06-25570 | • • SWITCH ASS'Y | 1 | SN: 50001- |
|||
| ? | 421-06-25560 | • • SPRING | 1 | SN: 50001- |
|||
| ? | 01235-40530 | • • SCREW | 1 | SN: 50001- |
|||
| ? | 01601-20513 | • • WASHER,SPRING | 1 | SN: 50001- |
|||
| ? | 01580-10504 | • • NUT | 1 | SN: 50001- |
|||
| ? | 421-09-21230 | • NUT | 1 | SN: 50001- |
|||
| ? | 421-43-28431 | • BOOT | 1 | SN: .- |
|||
| ? | (☒421-43-28430) | • BOOT | 1 | SN: (50001-.) |
|||
| ? | 423-43-18350 | • GROMMET | 1 | SN: 50001- |
|||
| ? | 421-V91-2130 | LEVER | 1 | SN: 50001- |
|||
| ? | 06124-02020 | BEARING | 4 | SN: 50001- |
|||
| ? | 421-V91-2210 | LEVER | 1 | SN: 50001- |
|||
| ? | 06124-02020 | BEARING | 1 | SN: 50001- |
|||
| ? | 419-V91-1190 | PIN | 1 | SN: 50001- |
|||
| ? | 419-V91-1210 | SPACER | 1 | SN: 50001- |
|||
| ? | 01435-00612 | BOLT | 1 | SN: 50001- |
|||
| ? | 421-V91-2320 | SPACER | 1 | SN: 50001- |
|||
| ? | 426-43-18850 | SHIM¤ 1.0MM | 5 | SN: 50001- |
|||
| ? | 421-43-28210 | SHAFT | 1 | SN: 50001- |
|||
| ? | 04025-00616 | PIN,SPRING | 1 | SN: 50001- |
|||
| ? | 425-43-18114 | PLATE,LIFT | 1 | SN: 50001- |
|||
| ? | 425-43-18252 | PLATE,BUCKET | 1 | SN: 50001- |
|||
| ? | 04020-00616 | PIN,DOWEL | 4 | SN: 50001- |
|||
| ? | 01435-00825 | BOLT | 2 | SN: 50001- |
|||
| ? | 01584-00806 | NUT | 2 | SN: 50001- |
|||
| ? | 421-V91-2260 | BRACKET | 1 | SN: 50001- |
|||
| ? | 01435-01016 | BOLT | 3 | SN: 50001- |
|||
| ? | 421-V91-2460 | LEVER ASS'Y | 1 | SN: 50001- |
|||
| ? | 421-43-18850 | • BUSHING | 2 | SN: 50001- |
|||
| ? | 425-43-18320 | LEVER ASS'Y | 1 | SN: 50001- |
|||
| ? | 421-43-18850 | • BUSHING | 2 | SN: 50001- |
|||
| ? | 421-43-18711 | BEARING | 2 | SN: 50001- |
|||
| ? | 01643-30623 | WASHER | 4 | SN: 50001- |
|||
| ? | 01580-10605 | NUT | 2 | SN: 50001- |
|||
| ? | 01643-31232 | WASHER | 2 | SN: 50001- |
|||
| ? | 04050-13022 | PIN,COTTER | 2 | SN: 50001- |
|||
| ? | 421-06-11542 | SOLENOID | 2 | SN: 50001- |
|||
| ? | 01435-00616 | BOLT | 8 | SN: 50001- |
|||
| ? | 425-43-18140 | PLATE | 4 | SN: 50001- |
|||
| ? | 04205-10620 | PIN | 4 | SN: 50001- |
|||
| ? | 01641-20608 | WASHER | 8 | SN: 50001- |
|||
| ? | 04050-11610 | PIN,COTTER | 4 | SN: 50001- |
|||
| ? | 234-885-1690 | SPRING | 2 | SN: 50001- |
|||
| ? | 421-V91-2290 | PLATE | 1 | SN: 50001- |
|||
| ? | 01220-70620 | SCREW | 4 | SN: 50001- |
|||
| ? | 01642-40608 | WASHER | 4 | SN: 50001- |
