| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 419-877-2110 | TUBE | 1 | SN: 50001- |
|||
| ? | 419-877-2120 | TUBE | 1 | SN: 50001- |
|||
| ? | 419-V88-2120 | TUBE | 1 | SN: 50001- |
|||
| ? | 419-V88-2140 | TUBE | 1 | SN: 50001- |
|||
| ? | 419-V88-2110 | TUBE | 1 | SN: 50001- |
|||
| ? | 419-V88-2130 | TUBE | 1 | SN: 50001- |
|||
| ? | 07000-13032 | O-RING | 2 | SN: 50001- |
|||
| ? | 07372-21040 | BOLT | 8 | SN: 50001- |
|||
| ? | 01643-51032 | WASHER | 8 | SN: 50001- |
|||
| ? | 07230-20628 | UNION | 2 | SN: 50001- |
|||
| ? | 07235-10628 | ELBOW | 1 | SN: 50001- |
|||
| ? | 415-V93-1270 | UNION | 1 | SN: 50001- |
|||
| ? | 07002-12434 | O-RING | 4 | SN: 50001- |
|||
| ? | 07125-00612 | HOSE | 6 | SN: 50001- |
|||
| ? | 419-877-1532 | TUBE,L.H. | 1 | SN: 50001- |
|||
| ? | 419-V89-2340 | TUBE,L.H. | 1 | SN: 50001- |
|||
| ? | 419-V88-1770 | TUBE,L.H. | 1 | SN: 50001- |
|||
| ? | 419-V88-1760 | TUBE,R.H. | 1 | SN: 50001- |
|||
| ? | 419-V89-1320 | TUBE,R.H. | 1 | SN: 50001- |
|||
| ? | 419-877-1522 | TUBE,R.H. | 1 | SN: 50001- |
|||
| ? | 07000-13025 | O-RING | 12 | SN: 50001- |
|||
| ? | 07371-30640 | FLANGE,SPLIT | 12 | SN: 50001- |
|||
| ? | 07371-30638 | FLANGE,SPLIT | 12 | SN: 50001- |
|||
| ? | 07372-21035 | BOLT | 24 | SN: 50001- |
|||
| ? | 01643-51032 | WASHER | 24 | SN: 50001- |
|||
| ? | 01010-50835 | BOLT | 24 | SN: 50001- |
|||
| ? | 01643-50823 | WASHER | 24 | SN: 50001- |
|||
| ? | 07378-10600 | HEAD | 6 | SN: 50001- |
|||
| ? | 07000-13025 | O-RING | 6 | SN: 50001- |
|||
| ? | 07371-30638 | FLANGE,SPLIT | 12 | SN: 50001- |
|||
| ? | 01010-50835 | BOLT | 24 | SN: 50001- |
|||
| ? | 01643-50823 | WASHER | 24 | SN: 50001- |
