| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 418-06-33211 | LAMP,HEAD¤ L.H. | 1 | SN: 65001- |
|||
| ? | 418-06-33440 | • LENS | 1 | SN: 65001- |
|||
| ? | 418-06-33460 | • SCREW | 4 | SN: 65001- |
|||
| ? | 418-06-33430 | • BULB¤ 24V | 1 | SN: 65001- |
|||
| ? | 418-06-33450 | • LENS | 1 | SN: 65001- |
|||
| ? | 418-06-33420 | • BULB¤ 24V | 1 | SN: 65001- |
|||
| ? | 418-06-33410 | • LAMP | 1 | SN: 65001- |
|||
| ? | 424-06-23230 | • BULB¤ 75/70W | 1 | SN: 65001- |
|||
| ? | 08055-10612 | • BODY | 1 | SN: 65001- |
|||
| ? | 08055-10630 | • HOLDER | 1 | SN: 65001- |
|||
| ? | 418-06-33221 | LAMP,HEAD¤ R.H. | 1 | SN: 65001- |
|||
| ? | 418-06-33440 | • LENS | 1 | SN: 65001- |
|||
| ? | 418-06-33460 | • SCREW | 4 | SN: 65001- |
|||
| ? | 418-06-33430 | • BULB¤ 24V | 1 | SN: 65001- |
|||
| ? | 418-06-33450 | • LENS | 1 | SN: 65001- |
|||
| ? | 418-06-33420 | • BULB¤ 24V | 1 | SN: 65001- |
|||
| ? | 418-06-33410 | • LAMP | 1 | SN: 65001- |
|||
| ? | 424-06-23230 | • BULB¤ 75/70W | 1 | SN: 65001- |
|||
| ? | 08055-10612 | • BODY | 1 | SN: 65001- |
|||
| ? | 08055-10630 | • HOLDER | 1 | SN: 65001- |
|||
| ? | 207-54-16860 | GROMMET | 2 | SN: 65001- |
|||
| ? | 209-09-11340 | WASHER | 2 | SN: 65001- |
|||
| ? | 418-06-33115 | SUPPORT,L.H. | 1 | SN: 65001- |
|||
| ? | 418-06-33125 | SUPPORT,R.H. | 1 | SN: 65001- |
|||
| ? | 01010-81025 | BOLT | 6 | SN: 65001- |
|||
| ? | 01643-31032 | WASHER | 6 | SN: 65001- |
|||
| ? | 09415-03614 | CAP | 2 | SN: 65001- |
|||
| ? | 01023-10612 | SCREW | 8 | SN: 65001- |
|||
| ? | 418-06-33191 | PLATE | 2 | SN: 65001- |
