| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 417-23-30010 | AXLE ASS'Y,REAR | 1 | SN: 65001- |
|||
| ? | 417-23-30050 | AXLE ASS'Y,REAR (ASD) | 1 | SN: 65001- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F4500-51A0 TO F4500-54A0. | ||||||
| ? | 417-22-32532 | • GEAR | 6 | SN: 65001- |
|||
| ? | 417-22-22810 | • BEARING,CONE | 12 | SN: 65001- |
|||
| ? | 417-22-32613 | • CARRIER | 2 | SN: 65001- |
|||
| ? | 417-22-12351 | • SPACER | 2 | SN: 65001- |
|||
| ? | 417-22-12510 | • SHAFT | 6 | SN: 65001- |
|||
| ? | 419-22-12570 | • PIN | 6 | SN: 65001- |
|||
| ? | 417-22-32410 | • SHAFT,AXLE | 2 | SN: 65001- |
|||
| ? | 417-22-12850 | • BEARING | 2 | SN: 65001- |
|||
| ? | 417-22-12460 | • SEAL | 2 | SN: 65001- |
|||
| ? | 417-22-12840 | • BEARING | 2 | SN: 65001- |
|||
| ? | 417-22-32542 | • GEAR,RING | 2 | SN: 65001- |
|||
| ? | 415-22-22580 | • PIN | 8 | SN: 65001- |
|||
| ? | 01010-61685 | • BOLT | 2 | SN: 65001- |
|||
| ? | 417-22-12360 | • SHIM¤ 0.05MM | 2 | SN: 65001- |
|||
| ? | 417-22-12370 | • SHIM¤ 0.2MM | 4 | SN: 65001- |
|||
| ? | 417-22-12380 | • SHIM¤ 0.3MM | 6 | SN: 65001- |
|||
| ? | 417-22-12390 | • SHIM¤ 0.8MM | 2 | SN: 65001- |
|||
| ? | 417-22-32422 | • SHAFT,SUN | 2 | SN: 65001- |
|||
| ? | 417-23-33710 | • HOUSING,L.H. | 1 | SN: 65001- |
|||
| ? | 417-23-33720 | • HOUSING,R.H. | 1 | SN: 65001- |
|||
| ? | 815-02-10110 | • PLATE¤ NAME,LIMITED SUPPLY | 1 | SN: 65001- |
|||
| ? | 04418-13060 | • SCREW | 4 | SN: 65001- |
|||
| ? | 07030-01030 | • BREATHER | 1 | SN: 65001- |
