| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (416-18-31801) | MOTOR | 1 | SN: 65001- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1651-01A1 TO Y1651-06A1. | ||||||
| ? | UC4020753283 | • CONTROL ASS'Y | 1 | SN: 65001- |
|||
| ? | (★UC1020772296) | • • HOUSING | 1 | SN: 65001- |
|||
| ? | (★UC1094326623) | • • BUSHING | 1 | SN: 65001- |
|||
| ? | (★UC1020069563) | • • CONTROL PISTON | 1 | SN: 65001- |
|||
| ? | (★UC1706511182) | • • SPRING | 1 | SN: 65001- |
|||
| ? | (★UC1709213395) | • • SPRING | 1 | SN: 65001- |
|||
| ? | (★UC1709214196) | • • SPRING | 1 | SN: 65001- |
|||
| ? | (★UC1706511164) | • • SPRING | 1 | SN: 65001- |
|||
| ? | (★UC1020451292) | • • CONTROL PISTON | 1 | SN: 65001- |
|||
| ? | (★UC1096501963) | • • BUSHING | 1 | SN: 65001- |
|||
| ? | (★UC1020450648) | • • SPRING | 1 | SN: 65001- |
|||
| ? | UC1301544006 | • • BOLT | 4 | SN: 65001- |
|||
| ? | (★UC1700833817) | • • WASHER | 1 | SN: 65001- |
|||
| ? | (★UC1302086116) | • • SCREW | 1 | SN: 65001- |
|||
| ? | (★UC1700877569) | • • PIN | 1 | SN: 65001- |
|||
| ? | (★UC1701524257) | • • NUT | 1 | SN: 65001- |
|||
| ? | (★UC1701538687) | • • PLUG | 5 | SN: 65001- |
|||
| ? | (★UC1300083005) | • • O-RING | 1 | SN: 65001- |
|||
| ? | (★UC4020757708) | • • SOLENOID | 2 | SN: 65001- |
