| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (708-7R-00650) | MOTOR ASS'Y | 1 | SN: 65001- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1642-11A0 AND Y1642-12A0. | ||||||
| ? | (★07000-12095) | • O-RING | 1 | SN: 65001- |
|||
| ? | (★720-68-19610) | • PIN | 2 | SN: 65001- |
|||
| ? | (★01010-81070) | • BOLT | 4 | SN: 65001- |
|||
| ? | (★708-7R-12210) | • SHAFT | 1 | SN: 65001- |
|||
| ? | (★708-7R-12220) | • BEARING | 1 | SN: 65001- |
|||
| ? | (★708-7S-12220) | • BEARING | 1 | SN: 65001- |
|||
| ? | (★708-7S-05110) | • SHIM KIT | 1 | SN: 65001- |
|||
| ? | ☆ | • • SHIM¤ 0.85MM | 1 | SN: 65001- |
|||
| ? | ☆ | • • SHIM¤ 1.05MM | 1 | SN: 65001- |
|||
| ? | ☆ | • • SHIM¤ 1.25MM | 1 | SN: 65001- |
|||
| ? | ☆ | • • SHIM¤ 0.75MM | 1 | SN: 65001- |
|||
| ? | ☆ | • • SHIM¤ 0.95MM | 1 | SN: 65001- |
|||
| ? | ☆ | • • SHIM¤ 1.15MM | 1 | SN: 65001- |
|||
| ? | (★708-7R-12240) | • SEAL,OIL | 1 | SN: 65001- |
|||
| ? | (★04065-04218) | • RING | 1 | SN: 65001- |
|||
| ? | (★708-7R-13111) | • BLOCK,CYLINDER | 1 | SN: 65001- |
|||
| ? | (★708-7R-13610) | • PLATE,VALVE | 1 | SN: 65001- |
|||
| ? | (★720-68-19610) | • PIN | 1 | SN: 65001- |
|||
| ? | (★708-7R-13540) | • PIN | 3 | SN: 65001- |
|||
| ? | (★708-7R-13530) | • WASHER | 2 | SN: 65001- |
|||
| ? | (★708-7R-13560) | • SPRING | 1 | SN: 65001- |
|||
| ? | 04065-03012 | • RING | 1 | SN: 65001- |
|||
| ? | 708-7R-13590 | • GUIDE,RETAINER | 1 | SN: 65001- |
|||
| ? | 708-7R-13340 | • RETAINER,SHOE | 1 | SN: 65001- |
|||
| ? | 708-7R-13320 | • PISTON SUB ASS'Y | 7 | SN: 65001- |
|||
| ? | 708-7R-13620 | • PLATE | 1 | SN: 65001- |
