| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 708-7R-00650 | MOTOR ASS'Y | 1 | SN: 65001- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1642-11A0 AND Y1642-12A0. | ||||||
| ? | (★708-7R-11930) | • CASE | 1 | SN: 65001- |
|||
| ? | 07040-11007 | • PLUG | 1 | SN: 65001- |
|||
| ? | 07002-11023 | • O-RING | 1 | SN: 65001- |
|||
| ? | (★708-7R-01650) | • COVER SUB ASS'Y | 1 | SN: 65001- |
|||
| ? | ☆ | • • COVER,END | 1 | SN: 65001- |
|||
| ? | 708-7R-11220 | • • PLUG | 2 | SN: 65001- |
|||
| ? | 07002-11223 | • • O-RING | 2 | SN: 65001- |
|||
| ? | 07040-11409 | • • PLUG | 1 | SN: 65001- |
|||
| ? | 07002-11423 | • • O-RING | 1 | SN: 65001- |
|||
| ? | ☆ | • • SPOOL | 1 | SN: 65001- |
|||
| ? | 708-7R-03110 | • • VALVE ASS'Y,RELIEF | 1 | SN: 65001- |
|||
| ? | ☆ | • • SPOOL | 1 | SN: 65001- |
|||
| ? | (★708-7R-18340) | • • SCREW | 1 | SN: 65001- |
|||
| ? | 01580-10806 | • • NUT | 1 | SN: 65001- |
|||
| ? | (★07000-11007) | • • O-RING | 1 | SN: 65001- |
|||
| ? | (★708-7R-18350) | • • PLUG | 1 | SN: 65001- |
|||
| ? | (★07002-12034) | • • O-RING | 1 | SN: 65001- |
|||
| ? | 708-7R-21110 | • • PLUG | 1 | SN: 65001- |
|||
| ? | 07002-13334 | • • O-RING | 1 | SN: 65001- |
|||
| ? | 708-7R-21120 | • • SPRING | 1 | SN: 65001- |
|||
| ? | 708-7R-18360 | • • PLATE | 1 | SN: 65001- |
|||
| ? | 07000-11010 | • • O-RING | 1 | SN: 65001- |
|||
| ? | 702-21-55440 | • • O-RING | 2 | SN: 65001- |
|||
| ? | 01010-80820 | • • BOLT | 4 | SN: 65001- |
