| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (705-56-34690) | PUMP ASS'Y,(SAR(3)63+SB(1)10+6) | 1 | SN: 65001- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1610-01A0 TO Y1610-03A0. | ||||||
| ? | 705-41-04480 | • PUMP ASS'Y,(SBR(1)10) | 1 | SN: 65001- |
|||
| ? | (★705-41-85010) | • • BRACKET | 1 | SN: 65001- |
|||
| ? | (★705-40-80610) | • • • BUSHING,PLANE | 1 | SN: 65001- |
|||
| ? | (★705-40-80620) | • • • BUSHING,PLANE | 1 | SN: 65001- |
|||
| ? | (★705-40-22011) | • • CASE,GEAR | 1 | SN: 65001- |
|||
| ? | (★705-40-80311) | • • CARRIER | 1 | SN: 65001- |
|||
| ? | (★705-40-80610) | • • • BUSHING,PLANE | 1 | SN: 65001- |
|||
| ? | (★705-40-80620) | • • • BUSHING,PLANE | 1 | SN: 65001- |
|||
| ? | (★705-40-22540) | • • GEAR,DRIVE | 1 | SN: 65001- |
|||
| ? | (★705-40-22511) | • • GEAR,DRIVEN | 1 | SN: 65001- |
|||
| ? | (★705-40-83720) | • • PLATE,SIDE | 2 | SN: 65001- |
|||
| ? | (★705-40-80770) | • • SEAL,OIL | 2 | SN: 65001- |
|||
| ? | (★04020-00820) | • • PIN,DOWEL | 4 | SN: 65001- |
|||
| ? | (★04020-01228) | • • PIN,DOWEL | 2 | SN: 65001- |
|||
| ? | (★705-67-01230) | • • PIN,DOWEL | 2 | SN: 65001- |
|||
| ? | (★01252-61270) | • • BOLT | 4 | SN: 65001- |
|||
| ? | (★01643-51232) | • • WASHER | 4 | SN: 65001- |
|||
| ? | 705-67-01330 | • COUPLING ASS'Y | 1 | SN: 65001- |
|||
| ? | 705-17-03381 | • O-RING | 1 | SN: 65001- |
|||
| ? | 01252-61035 | • BOLT | 4 | SN: 65001- |
|||
| ? | 705-17-04980 | • WASHER | 4 | SN: 65001- |
|||
| ? | 705-40-80941 | • PLATE | 1 | SN: 65001- |
|||
| ? | 07000-E2021 | • O-RING | 1 | SN: 65001- |
|||
| ? | 01252-70825 | • BOLT | 4 | SN: 65001- |
|||
| ? | 01643-50823 | • WASHER | 4 | SN: 65001- |
