| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 421-07-21110 | DAMPER ASS'Y | 1 | SN: 60001- |
|||
| ? | ND017321-2130 | • CASE,AIR DAMPER | 1 | SN: 60001- |
|||
| ? | ND116471-6640 | • BRACKET,CASE | 2 | SN: 60001- |
|||
| ? | ND909300-6161 | • SCREW,TAPPING | 12 | SN: 60001- |
|||
| ? | ND116471-6650 | • BRACKET,CASE | 2 | SN: 60001- |
|||
| ? | ND017321-2140 | • CASE,AIR DAMPER | 1 | SN: 60001- |
|||
| ? | ND909000-4161 | • SCREW,TAPPING | 5 | SN: 60001- |
|||
| ? | ND116530-8720 | • DAMPER ASS'Y | 1 | SN: 60001- |
|||
| ? | ND017732-3321 | • LEVER,CONTROL | 1 | SN: 60001- |
|||
| ? | ND913700-4081 | • SCREW,WITH WASHER | 1 | SN: 60001- |
|||
| ? | ND146625-1920 | • BUSHING | 1 | SN: 60001- |
|||
| ? | ND063700-4320 | • SERVO MOTOR ASS'Y | 1 | SN: 60001- |
|||
| ? | ND909000-5161 | • SCREW,TAPPING | 3 | SN: 60001- |
|||
| ? | ND116862-0621 | • WIRE | 1 | SN: 60001- |
|||
| ? | ND116471-6662 | • BRACKET,CASE | 1 | SN: 60001- |
|||
| ? | ND017773-0190 | • CLIP | 1 | SN: 60001- |
|||
| ? | ND909400-5121 | • SCREW,TAPPING | 12 | SN: 60001- |
|||
| ? | ND116471-6672 | • BRACKET,CASE | 1 | SN: 60001- |
|||
| ? | ND146984-4030 | • GROMMET | 1 | SN: 60001- |
|||
| ? | ND146370-5500 | • COVER ASS'Y | 1 | SN: 60001- |
|||
| ? | ND014520-0280 | • FILTER | 1 | SN: 60001- |
|||
| ? | ND014520-0290 | • FILTER SUB ASS'Y | 1 | SN: 60001- |
|||
| ? | ND146370-4911 | • COVER ASS'Y | 1 | SN: 60001- |
|||
| ? | ND902050-6270 | • WASHER | 2 | SN: 60001- |
|||
| ? | ND484923-0020 | • KNOB | 2 | SN: 60001- |
|||
| ? | ND146638-9501 | • PACKING | 1 | SN: 60001- |
|||
| ? | ND146648-1180 | • PACKING | 2 | SN: 60001- |
|||
| ? | ND017231-0670 | • CLAMP | 1 | SN: 60001- |
|||
| ? | ND246634-6681 | • BRACKET | 1 | SN: 60001- |
|||
| ? | ND909300-4101 | • SCREW,TAPPING | 2 | SN: 60001- |
|||
| ? | ND146648-6790 | • PACKING | 1 | SN: 60001- |
|||
| ? | ND246634-8580 | • BRACKET | 1 | SN: 60001- |
|||
| ? | ND905770-4001 | • E-RING | 2 | SN: 60001- |
