| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (418-23-20050) | AXLE ASS'Y,REAR (LIMITED SLIP DIFF.) | 1 | SN: 63001- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F4500-01A0 TO F4500-03A0. | ||||||
| ? | 418-22-21250 | • COUPLING | 1 | SN: 63001- |
|||
| ? | 418-22-21310 | • PROTECTOR | 1 | SN: 63001- |
|||
| ? | 417-15-13770 | • HOLDER | 1 | SN: 63001- |
|||
| ? | 01011-61615 | • BOLT | 1 | SN: 63001- |
|||
| ? | 418-22-21330 | • SEAL | 1 | SN: 63001- |
|||
| ? | 418-22-11820 | • BEARING | 1 | SN: 63001- |
|||
| ? | 418-22-11810 | • BEARING | 1 | SN: 63001- |
|||
| ? | 418-22-11861 | • SPACER | 1 | SN: 63001- |
|||
| ? | 07000-13040 | • O-RING | 1 | SN: 63001- |
|||
| ? | 418-23-21130 | • CAGE | 1 | SN: 63001- |
|||
| ? | 418-22-27260 | • PINION ASS'Y | 1 | SN: 63001- |
|||
| ? | ☆ | • • GEAR,BEVEL | 1 | SN: 63001- |
|||
| ? | ☆ | • • PINION | 1 | SN: 63001- |
|||
| ? | 07000-15160 | • O-RING | 1 | SN: 63001- |
|||
| ? | 418-22-27200 | • DIFFERENTIAL,(SERVICE ONLY) | 1 | SN: 63001- |
|||
| ? | 418-22-27100 | • • DIFFERENTIAL | 1 | SN: 63001- |
|||
| ? | 418-22-27110 | • • • CASE | 1 | SN: 63001- |
|||
| ? | 418-22-27210 | • • • RING,PRESSURE | 2 | SN: 63001- |
|||
| ? | 418-22-27220 | • • • SHAFT | 1 | SN: 63001- |
|||
| ? | 418-22-27310 | • • • PINION | 4 | SN: 63001- |
|||
| ? | 418-22-27320 | • • • GEAR | 2 | SN: 63001- |
|||
| ? | 418-22-27410 | • • • DISC | 4 | SN: 63001- |
|||
| ? | 418-22-27450 | • • • PLATE,3.0MM | 4 | SN: 63001- |
|||
| ? | 418-22-27460 | • • • PLATE,3.1MM | 4 | SN: 63001- |
|||
| ? | 417-22-27370 | • • • WASHER,2.0MM | 2 | SN: 63001- |
|||
| ? | 417-22-27380 | • • • WASHER,2.1MM | 2 | SN: 63001- |
|||
| ? | 418-22-27190 | • • COVER,(FOR SERVICE OR SHIPPING) | 1 | SN: 63001- |
|||
| ? | 01010-61625 | • • BOLT,(FOR SERVICE OR SHIPPING) | 4 | SN: 63001- |
|||
| ? | 01010-31640 | • BOLT | 16 | SN: 63001- |
|||
| ? | 417-22-11850 | • BEARING | 2 | SN: 63001- |
|||
| ? | 418-22-21160 | • CARRIER | 2 | SN: 63001- |
|||
| ? | 418-23-23110 | • HOUSING | 1 | SN: 63001- |
|||
| ? | 07043-70211 | • PLUG | 2 | SN: 63001- |
|||
| ? | 07044-13620 | • PLUG | 1 | SN: 63001- |
|||
| ? | 07002-13634 | • O-RING | 1 | SN: 63001- |
|||
| ? | 419-22-13140 | • PLUG | 2 | SN: 63001- |
|||
| ? | 07002-13034 | • O-RING | 2 | SN: 63001- |
|||
| ? | 01010-31230 | • BOLT | 14 | SN: .- |
|||
| ? | ♦01010-61230 | • BOLT | 14 | SN: 63001-. |
|||
| ? | 418-22-21510 | • SHIM¤ 0.05MM | 6 | SN: 63001- |
|||
| ? | 418-22-21520 | • SHIM¤ 0.2MM | 3 | SN: 63001- |
|||
| ? | 418-22-21530 | • SHIM¤ 0.3MM | 3 | SN: 63001- |
|||
| ? | 418-22-21540 | • SHIM¤ 0.8MM | 2 | SN: 63001- |
|||
| ? | 418-33-21430 | • RING | 2 | SN: 63001- |
|||
| ? | 418-33-21420 | • O-RING | 2 | SN: 63001- |
|||
| ? | 417-22-11360 | • SHIM¤ 0.05MM | 2 | SN: 63001- |
|||
| ? | 417-22-11370 | • SHIM¤ 0.2MM | 2 | SN: 63001- |
|||
| ? | 417-22-11380 | • SHIM¤ 0.3MM | 2 | SN: 63001- |
|||
| ? | 417-22-11390 | • SHIM¤ 0.8MM | 1 | SN: 63001- |
|||
| ? | 01010-31235 | • BOLT | 13 | SN: .- |
|||
| ? | ♦01010-61235 | • BOLT | 13 | SN: 63001-. |
|||
| ? | 01643-31232 | • WASHER | 13 | SN: 63001- |
|||
| ? | 418-33-21120 | • PISTON | 2 | SN: 63001- |
|||
| ? | 418-33-21410 | • O-RING | 2 | SN: 63001- |
|||
| ? | 07040-11209 | • PLUG | 2 | SN: 63001- |
|||
| ? | 07002-11223 | • O-RING | 2 | SN: 63001- |
|||
| ? | 419-33-11460 | • BLEEDER | 2 | SN: 63001- |
|||
| ? | 418-22-23120 | • COVER | 1 | SN: 63001- |
|||
| ? | 04020-01228 | • PIN,DOWEL | 2 | SN: 63001- |
|||
| ? | 01010-61230 | • BOLT | 16 | SN: 63001- |
|||
| ? | 01643-31232 | • WASHER | 16 | SN: 63001- |
|||
| ? | 566-32-11620 | • CAP | 2 | SN: 63001- |
|||
| ? | 418-33-21251 | • PLATE | 2 | SN: 63001- |
