| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO. | ||||||
| ? | (714-13-10012) | TORQFLOW ASS'Y,(FOR EMERGENCY STEERING) | 1 | SN: 63473- |
|||
| ? | (714-13-10011) | TORQFLOW ASS'Y,(FOR EMERGENCY STEERING) | 1 | SN: 63001-63472 |
|||
| ? | (714-13-10210) | TORQFLOW ASS'Y,(TACHOGRAPH & KAISOU) | 1 | SN: 64001- |
|||
| ? | THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A1 TO F4350-70A1. | ||||||
| ? | (714-11-15030) | • CONTROL VALVE ASS'Y | 1 | SN: (77721)- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-61A1 TO F4350-63A1A. | ||||||
| ? | (714-11-16200) | • • VALVE ASS'Y,LOWER | 1 | SN: (77721)- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-62A1 AND F4350-63A1A . | ||||||
| ? | 714-11-16900 | • • • VALVE ASS'Y,SOLENOID | 1 | SN: (77721)- |
|||
| ? | 714-11-16800 | • • • • BODY ASS'Y,SOLENOID | 1 | SN: (77721)- |
|||
| ? | 714-11-16830 | • • • • • SOLENOID VALVE | 2 | SN: (77721)- |
|||
| ? | 714-11-16840 | • • • • • SOLENOID VALVE | 2 | SN: (77721)- |
|||
| ? | 714-11-16811 | • • • • BRACKET | 1 | SN: (77721)- |
|||
| ? | 01010-80816 | • • • • BOLT | 2 | SN: (77721)- |
|||
| ? | 01643-30823 | • • • • WASHER | 2 | SN: (77721)- |
|||
| ? | 01010-81085 | • • • BOLT | 1 | SN: (77721)- |
|||
| ? | 01011-81015 | • • • BOLT | 1 | SN: (77721)- |
|||
| ? | 01011-81015 | • • • BOLT | 4 | SN: (77721)- |
|||
| ? | 01010-81085 | • • • BOLT | 2 | SN: (77721)- |
|||
| ? | 01010-81085 | • • • BOLT | 1 | SN: (77721)- |
|||
| ? | 01643-31032 | • • • WASHER | 10 | SN: (77721)- |
|||
| ? | 195-30-34260 | • • • WASHER | 1 | SN: (77721)- |
|||
| ? | 419-06-12840 | • • • PLATE | 1 | SN: 63001- |
|||
| ? | 07043-70108 | • • • PLUG | 1 | SN: 63001- |
|||
| ? | 419-15-16811 | • • GASKET (K2) | 1 | SN: 63001- |
|||
| ? | 01010-80860 | • • BOLT | 1 | SN: 63001- |
|||
| ? | 01010-80875 | • • BOLT | 1 | SN: 63001- |
|||
| ? | 419-15-16660 | • • FILTER ASS'Y | 1 | SN: 63001- |
|||
| ? | 07000-02014 | • • O-RING (K2) | 2 | SN: 63001- |
|||
| ? | 01010-81035 | • • BOLT | 2 | SN: 63001- |
|||
| ? | 01602-01030 | • • WASHER,SPRING | 2 | SN: 63001- |
|||
| ? | 01642-21016 | • • WASHER | 2 | SN: 63001- |
