| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO. | ||||||
| ? | (714-13-10012) | TORQFLOW ASS'Y | 1 | SN: 63473- |
|||
| ? | (714-13-10011) | TORQFLOW ASS'Y | 1 | SN: 63001-63472 |
|||
| ? | (714-13-10210) | TORQFLOW ASS'Y,(TACHOGRAPH & KAISOU) | 1 | SN: 64001- |
|||
| ? | THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A1 TO F4350-70A1. | ||||||
| ? | 714-13-12010 | • CLUTCH ASS'Y,FORWARD AND REVERSE | 1 | SN: 63001- |
|||
| ? | 714-13-12040 | • CLUTCH ASS'Y,FORWARD&REVERSE(TACHO&KAISOU) | 1 | SN: 64001- |
|||
| ? | 714-13-12110 | • • SHAFT ASS'Y | 1 | SN: 63001- |
|||
| ? | ☆ | • • • SHAFT,INPUT | 1 | SN: 63001- |
|||
| ? | 417-15-12250 | • • • CHOKE | 1 | SN: 63001- |
|||
| ? | 714-11-19390 | • • • BALL | 2 | SN: 63001- |
|||
| ? | ☆ | • • • CYLINDER | 1 | SN: 63001- |
|||
| ? | 714-13-12360 | • • HOUSING ASS'Y | 1 | SN: 63001- |
|||
| ? | 714-13-12650 | • • PISTON,FORWARD AND REVERSE | 2 | SN: 63001- |
|||
| ? | 714-12-19711 | • • DISC | 14 | SN: (77655)- |
|||
| ? | □714-12-19710 | • • DISC | 14 | SN: 63001-(77654) |
|||
| ? | 714-16-19730 | • • PLATE,SEPARATE | 16 | SN: 63001- |
|||
| ? | 56D-15-12710 | • • SPRING,WAVE | 14 | SN: 64452- |
|||
| ? | 419-15-12133 | • • SPRING,WAVE | 14 | SN: 63001-64451 |
|||
| ? | 714-12-12610 | • • PLATE,END | 2 | SN: 63001- |
|||
| ? | 419-15-12140 | • • RING,SNAP | 4 | SN: 63001- |
|||
| ? | 714-13-19210 | • • RING,SEAL | 2 | SN: 63001- |
|||
| ? | 714-16-19210 | • • RING,SEAL | 2 | SN: 63001- |
|||
| ? | 714-11-19510 | • • WASHER,THRUST | 4 | SN: 63001- |
|||
| ? | 419-15-12271 | • • BEARING,NEEDLE | 3 | SN: 64001- |
|||
| ? | 419-15-12270 | • • BEARING,NEEDLE | 3 | SN: 63001-64000 |
|||
| ? | 714-11-12710 | • • SPACER | 2 | SN: 63001- |
|||
| ? | 06040-06210 | • • BEARING | 1 | SN: 63001- |
|||
| ? | 714-13-19310 | • • BEARING | 1 | SN: 63001- |
|||
| ? | 714-13-12420 | • • GEAR¤ 38 TEETH,FORWARD | 1 | SN: 63001- |
|||
| ? | 714-13-12470 | • • GEAR¤ 38 TEETH,FORWARD (TACHOGRAPH & KAISOU) | 1 | SN: 64001- |
|||
| ? | 714-13-12410 | • • GEAR¤ 22 TEETH,REVERSE | 1 | SN: 63001- |
|||
| ? | 714-13-12540 | • • GEAR¤ 21 TEETH,REVERSE (TACHOGRAPH & KAISOU) | 1 | SN: 64001- |
|||
| ? | 419-15-12122 | • RING,SEAL | 4 | SN: 63001- |
