| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (707-00-X7390) | CYLINDER GROUP,LIFT | 2 | SN: 64001- |
|||
| ? | (707-00-03151) | CYLINDER ASS'Y,LIFT | 2 | SN: 63001-64000 |
|||
| ? | 419-62-13790 | HOSE | 4 | SN: 63001- |
|||
| ? | 418-62-23270 | TUBE | 2 | SN: 63001-64000 |
|||
| ? | 418-62-23280 | TUBE | 2 | SN: 63001-64000 |
|||
| ? | 07235-10628 | ELBOW | 2 | SN: 63001-64000 |
|||
| ? | 07002-12434 | O-RING | 2 | SN: 63001-64000 |
|||
| ? | 07283-22738 | CLIP | 4 | SN: 63001-64000 |
|||
| ? | 01597-01009 | NUT | 8 | SN: 63001-64000 |
|||
| ? | 01643-31032 | WASHER | 8 | SN: 63001-64000 |
|||
| ? | 418-62-23290 | PLATE | 2 | SN: 63001-64000 |
|||
| ? | 426-35-11370 | SPACER | 2 | SN: 63001-64000 |
|||
| ? | 01435-01265 | BOLT | 2 | SN: 63001-64000 |
|||
| ? | 417-70-11590 | PIN | 2 | SN: 63001- |
|||
| ? | 07020-00000 | FITTING,GREASE | 2 | SN: 63001- |
|||
| ? | 418-70-11430 | SHIM¤ 1.5MM | 2 | SN: 63001- |
|||
| ? | 418-70-11440 | SHIM¤ 3.0MM | 2 | SN: 63001- |
|||
| ? | 01010-81625 | BOLT | 2 | SN: 63001- |
|||
| ? | 421-70-11280 | WASHER | 2 | SN: 63001- |
|||
| ? | 418-09-11110 | SEAL,DUST | 4 | SN: 63001-64000 |
|||
| ? | 418-70-11972 | PIN | 2 | SN: 63001- |
|||
| ? | 417-70-11340 | SHIM¤ 1.5MM | 4 | SN: 63001- |
|||
| ? | 07020-00000 | FITTING,GREASE | 2 | SN: 63001- |
|||
| ? | 01010-81625 | BOLT | 2 | SN: 63001- |
|||
| ? | 421-70-11280 | WASHER | 2 | SN: 63001- |
