| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 418-43-27110 | CYLINDER ASS'Y,BOOSTER | 1 | SN: 63001- |
|||
| ? | 418-43-27120 | • CYLINDER ASS'Y,BOOSTER | 1 | SN: 63001- |
|||
| ? | 417-43-17110 | • • CONNECTOR | 1 | SN: 63001- |
|||
| ? | 417-43-17140 | • • SPRING | 1 | SN: 63001- |
|||
| ? | 417-43-17150 | • • ROD | 1 | SN: 63001- |
|||
| ? | 417-43-17160 | • • SPOOL | 1 | SN: 63001- |
|||
| ? | 417-43-17170 | • • WASHER | 1 | SN: 63001- |
|||
| ? | 417-43-17180 | • • RING,SNAP | 1 | SN: 63001- |
|||
| ? | 417-43-17190 | • • SEAT,SPRING | 1 | SN: 63001- |
|||
| ? | 417-43-17210 | • • SPRING | 1 | SN: 63001- |
|||
| ? | 417-43-17220 | • • SPRING | 1 | SN: 63001- |
|||
| ? | 417-43-17230 | • • SEAT,SPRING | 1 | SN: 63001- |
|||
| ? | 417-43-17240 | • • PISTON,POWER | 1 | SN: 63001- |
|||
| ? | 417-43-17250 | • • O-RING (KIT) | 1 | SN: 63001- |
|||
| ? | 417-43-17260 | • • COVER | 1 | SN: 63001- |
|||
| ? | 417-43-17270 | • • SEAL (KIT) | 1 | SN: 63001- |
|||
| ? | 417-43-17280 | • • PLATE (KIT) | 1 | SN: 63001- |
|||
| ? | 417-43-17290 | • • RING,SNAP (KIT) | 1 | SN: 63001- |
|||
| ? | 417-43-17320 | • • O-RING (KIT) | 2 | SN: 63001- |
|||
| ? | 417-43-17330 | • • RING,SNAP (KIT) | 1 | SN: 63001- |
|||
| ? | 417-43-17340 | • • COVER,DUST (KIT) | 1 | SN: 63001- |
|||
| ? | 417-43-17351 | • • VALVE | 1 | SN: 63001- |
|||
| ? | 418-43-17720 | • • SPRING | 1 | SN: 63001- |
|||
| ? | 417-43-17381 | • • PLUG | 1 | SN: 63001- |
|||
| ? | 417-43-17390 | • • O-RING | 1 | SN: 63001- |
|||
| ? | 417-43-17490 | • • SCREW | 1 | SN: 63001- |
|||
| ? | 418-43-27130 | • CYLINDER ASS'Y,MASTER | 1 | SN: 63001- |
|||
| ? | 419-44-12510 | • • PISTON (KIT) | 1 | SN: 63001- |
|||
| ? | 419-44-12520 | • • PACKING (KIT) | 1 | SN: 63001- |
|||
| ? | 419-44-12530 | • • STOPPER | 1 | SN: 63001- |
|||
| ? | 417-43-27250 | • • PISTON (KIT) | 1 | SN: 63001- |
|||
| ? | 419-44-12560 | • • RING,SNAP (KIT) | 1 | SN: 63001- |
|||
| ? | 419-44-12550 | • • CONNECTOR | 2 | SN: 63001- |
|||
| ? | 417-43-17130 | • O-RING (KIT) | 1 | SN: 63001- |
|||
| ? | 01010-51035 | • BOLT | 4 | SN: 63001- |
|||
| ? | 01643-31032 | • WASHER | 4 | SN: 63001- |
|||
| ? | SERVICE KIT | ||||||
| ? | 417-43-05110 | SERVICE KIT,BOOSTER CYLINDER | 1 | SN: 63001- |
|||
| ? | 417-43-05100 | SERVICE KIT,MASTER CYLINDER | 1 | SN: 63001- |
