| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 415-17-20003 | TRANSFER ASS'Y | 1 | SN: 10050- |
|||
| ? | □415-17-20002 | TRANSFER ASS'Y | 1 | SN: 10001-10049 |
|||
| ? | THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.F2420-01A0 AND F2420-02A0. | ||||||
| ? | 415-17-21213 | • CASE,FRONT | 1 | SN: 10050- |
|||
| ? | □415-17-21212 | • CASE,FRONT | 1 | SN: 10001-10049 |
|||
| ? | 415-17-21251 | • CASE,REAR | 1 | SN: 10001- |
|||
| ? | 01010-31235 | • BOLT | 15 | SN: 10001- |
|||
| ? | 04020-01228 | • PIN,DOWEL | 2 | SN: 10001- |
|||
| ? | 07030-00252 | • BREATHER | 1 | SN: 10001- |
|||
| ? | 07044-12412 | • PLUG | 2 | SN: 10001- |
|||
| ? | 07002-12434 | • O-RING | 2 | SN: 10001- |
|||
| ? | 415-17-22311 | • GEAR | 1 | SN: 10001- |
|||
| ? | 06030-06013 | • BEARING | 2 | SN: 10001- |
|||
| ? | 415-17-23410 | • GEAR | 1 | SN: 10001- |
|||
| ? | 04064-05020 | • RING,SNAP | 1 | SN: 10001- |
|||
| ? | 06030-06210 | • BEARING | 1 | SN: 10001- |
|||
| ? | 06030-06208 | • BEARING | 1 | SN: 10001- |
|||
| ? | 415-17-24510 | • SHAFT,OUTPUT | 1 | SN: 10001- |
|||
| ? | 415-17-23850 | • WORM | 1 | SN: 10001- |
|||
| ? | 714-04-13660 | • COUPLING | 1 | SN: 10001- |
|||
| ? | 07000-13032 | • O-RING | 1 | SN: 10001- |
|||
| ? | 415-22-11241 | • HOLDER | 1 | SN: 10001- |
|||
| ? | 01010-61275 | • BOLT | 1 | SN: 10001- |
|||
| ? | 714-01-13650 | • COUPLING | 1 | SN: 10001- |
|||
| ? | 714-01-13660 | • • COUPLING | 1 | SN: 10001- |
|||
| ? | 415-15-13730 | • • COVER | 1 | SN: 10001- |
|||
| ? | 415-17-23511 | • COVER,GEAR | 1 | SN: 10001- |
|||
| ? | 415-17-23520 | • PLATE | 1 | SN: 10001- |
|||
| ? | 01010-61020 | • BOLT | 4 | SN: 10001- |
|||
| ? | 01643-31032 | • WASHER | 4 | SN: 10001- |
