| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 416-64-15101 | VALVE ASS'Y,STEERING | 1 | SN: 20001- |
|||
| ? | 416-64-15180 | • CONTROL ASS'Y | 1 | SN: 20001- |
|||
| ? | 416-64-15190 | • SPRING | 6 | SN: 20001- |
|||
| ? | 416-64-15410 | • PIN | 1 | SN: 20001- |
|||
| ? | 416-64-15160 | • PLATE,SPACER | 1 | SN: 20001- |
|||
| ? | 416-64-15170 | • DRIVE | 1 | SN: 20001- |
|||
| ? | 416-64-15140 | • GEROTOR | 1 | SN: 20001- |
|||
| ? | 416-64-15150 | • SPACER | 1 | SN: 20001- |
|||
| ? | 416-64-15130 | • CAP,END | 1 | SN: 20001- |
|||
| ? | 416-64-15520 | • O-RING (KIT) | 3 | SN: 20001- |
|||
| ? | 416-64-15120 | • SCREW | 7 | SN: 20001- |
|||
| ? | 416-64-15470 | • RETAINER | 1 | SN: 20001- |
|||
| ? | 416-64-15460 | • BALL | 1 | SN: 20001- |
|||
| ? | 416-64-15440 | • SEAT,CHECK | 1 | SN: 20001- |
|||
| ? | 416-64-15450 | • O-RING (KIT) | 1 | SN: 20001- |
|||
| ? | 416-64-15420 | • SCREW,SET | 1 | SN: 20001- |
|||
| ? | 416-64-15430 | • O-RING (KIT) | 1 | SN: 20001- |
|||
| ? | 416-64-15480 | • BEARING ASS'Y | 1 | SN: 20001- |
|||
| ? | 416-64-15490 | • • RACE,BEARING | 2 | SN: 20001- |
|||
| ? | 416-64-15510 | • • NEEDLE | 1 | SN: 20001- |
|||
| ? | 416-64-15570 | • O-RING (KIT) | 1 | SN: 20001- |
|||
| ? | 416-64-15590 | • RING,BACK-UP (KIT) | 1 | SN: 20001- |
|||
| ? | 417-64-15580 | • SEAL (KIT) | 1 | SN: 20001- |
|||
| ? | 416-64-15560 | • O-RING (KIT) | 1 | SN: 20001- |
|||
| ? | 416-64-15540 | • BUSHING | 1 | SN: 20001- |
|||
| ? | 416-64-15530 | • RING | 1 | SN: 20001- |
|||
| ? | 416-64-15550 | • SEAL,DUST (KIT) | 1 | SN: 20001- |
