| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (416-15-11003) | TRANSMISSION ASS'Y | 1 | SN: 30001- |
|||
| ? | (416-15-11002) | TRANSMISSION ASS'Y | 1 | SN: 20001-29999 |
|||
| ? | 417-15-14510 | • STRAINER ASS'Y | 1 | SN: 10001- |
|||
| ? | 417-15-14640 | • • STRAINER | 1 | SN: 10001- |
|||
| ? | 417-15-14660 | • • MAGNET | 5 | SN: 10001- |
|||
| ? | 417-15-14650 | • • SUPPORT | 1 | SN: 10001- |
|||
| ? | 417-15-14621 | • FLANGE | 1 | SN: 20001- |
|||
| ? | 07000-02085 | • O-RING (KIT) | 1 | SN: 10001- |
|||
| ? | 01010-31080 | • BOLT | 4 | SN: 20001- |
|||
| ? | 01643-31032 | • WASHER | 4 | SN: 10001- |
|||
| ? | 417-15-14610 | • HOSE | 1 | SN: 10001- |
|||
| ? | 07373-11000 | • SPACER | 1 | SN: 20001- |
|||
| ? | 07000-03028 | • O-RING (KIT) | 2 | SN: 20001- |
|||
| ? | 07371-01049 | • FLANGE | 2 | SN: 10001- |
|||
| ? | 07372-01040 | • BOLT | 4 | SN: 20001- |
|||
| ? | 01602-01030 | • WASHER,SPRING | 4 | SN: 10001- |
|||
| ? | (705-73-29010) | • PUMP ASS'Y | 1 | SN: 20001- |
|||
| ? | 07000-02085 | • O-RING (KIT) | 1 | SN: 10001- |
|||
| ? | 01010-31030 | • BOLT | 2 | SN: 10001- |
|||
| ? | 01643-31032 | • WASHER | 2 | SN: 10001- |
|||
| ? | 417-15-14541 | • TUBE | 1 | SN: 10001- |
|||
| ? | 07000-03028 | • O-RING (KIT) | 1 | SN: 10001- |
|||
| ? | 01010-30835 | • BOLT | 4 | SN: 10001- |
|||
| ? | 01602-00825 | • WASHER,SPRING | 4 | SN: 10001- |
|||
| ? | 07102-20608 | • HOSE | 1 | SN: 10001- |
|||
| ? | 419-15-14640 | • ELBOW | 1 | SN: 10001- |
|||
| ? | 07002-03334 | • O-RING (KIT) | 1 | SN: 10001- |
|||
| ? | 113-60-23120 | • NUT | 1 | SN: 10001- |
|||
| ? | (419-15-14800) | • FILTER ASS'Y | 1 | SN: 10001- |
|||
| ? | 417-15-14580 | • SUPPORT | 1 | SN: 10001- |
|||
| ? | 01010-31035 | • BOLT | 4 | SN: 10001- |
|||
| ? | 01643-31032 | • WASHER | 4 | SN: 10001- |
|||
| ? | 01010-31235 | • BOLT | 2 | SN: 20001- |
|||
| ? | 01010-31295 | • BOLT | 1 | SN: 20001- |
|||
| ? | 01643-31232 | • WASHER | 3 | SN: 10001- |
|||
| ? | 07102-20605 | • HOSE | 1 | SN: 10001- |
|||
| ? | 113-60-33270 | • NIPPLE | 1 | SN: 10001- |
|||
| ? | 07002-03334 | • O-RING (KIT) | 1 | SN: 10001- |
|||
| ? | 07232-20628 | • ELBOW | 1 | SN: 10001- |
|||
| ? | 07002-02434 | • O-RING (KIT) | 1 | SN: 10001- |
|||
| ? | 07239-12410 | • NUT | 1 | SN: 10001- |
|||
| ? | 581-04-22290 | • CLIP | 1 | SN: 10001- |
|||
| ? | 01010-31220 | • BOLT | 1 | SN: 10001- |
|||
| ? | 01643-31232 | • WASHER | 1 | SN: 10001- |
|||
| ? | 417-43-11420 | • PLATE | 1 | SN: 20001- |
|||
| ? | 417-15-14561 | • PLATE | 1 | SN: 10001- |
|||
| ? | 01010-31045 | • BOLT | 1 | SN: 10001- |
|||
| ? | 08036-23014 | • CLIP | 2 | SN: 10001- |
|||
| ? | 01010-31025 | • BOLT | 3 | SN: 10001- |
|||
| ? | 01643-31032 | • WASHER | 5 | SN: 10001- |
|||
| ? | 01580-01008 | • NUT | 2 | SN: 10001- |
