| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (416-15-11003) | TRANSMISSION ASS'Y | 1 | SN: 30001- |
|||
| ? | (416-15-11002) | TRANSMISSION ASS'Y | 1 | SN: 20001-29999 |
|||
| ? | 417-15-13610 | • SHAFT,OUTPUT | 1 | SN: 10001- |
|||
| ? | 417-15-13622 | • GEAR | 1 | SN: 10001- |
|||
| ? | 04064-06020 | • RING,SNAP | 1 | SN: 10001- |
|||
| ? | 417-15-13641 | • COVER,GEAR | 1 | SN: 10001- |
|||
| ? | 01010-31225 | • BOLT | 2 | SN: 10001- |
|||
| ? | 01643-31232 | • WASHER | 2 | SN: .- |
|||
| ? | 06002-30210 | • BEARING | 1 | SN: 10001- |
|||
| ? | 417-15-13631 | • RETAINER | 1 | SN: 20001- |
|||
| ? | 417-15-13690 | • SEAL,OIL (KIT) | 1 | SN: .- |
|||
| ? | 07000-02105 | • O-RING (KIT) | 1 | SN: 10001- |
|||
| ? | 417-15-13650 | • SHIM¤ 0.05MM | 20 | SN: 10001- |
|||
| ? | 417-15-13660 | • SHIM¤ 0.1MM | 12 | SN: 10001- |
|||
| ? | 417-15-13670 | • SHIM¤ 0.2MM | 8 | SN: 10001- |
|||
| ? | 01010-31235 | • BOLT | 6 | SN: 10001- |
|||
| ? | 01643-31232 | • WASHER | 6 | SN: 10001- |
|||
| ? | 417-15-13810 | • SEAL,DUST | 1 | SN: 20001- |
|||
| ? | 417-15-13722 | • COUPLING,FRONT | 1 | SN: 30001- |
|||
| ? | 416-15-13722 | • COUPLING,FRONT | 1 | SN: 20001-29999 |
|||
| ? | 417-15-13790 | • O-RING (KIT) | 1 | SN: 10001- |
|||
| ? | 417-15-13770 | • HOLDER | 1 | SN: 10001- |
|||
| ? | 01011-31610 | • BOLT | 1 | SN: 10001- |
|||
| ? | 417-22-15111 | • DISC,PARKING BRAKE | 1 | SN: 20001- |
|||
| ? | 01010-31235 | • BOLT | 6 | SN: 20001- |
|||
| ? | 01643-31232 | • WASHER | 6 | SN: 20001- |
|||
| ? | 06002-30210 | • BEARING | 1 | SN: 10001- |
|||
| ? | 417-15-13690 | • SEAL,OIL (KIT) | 1 | SN: .- |
|||
| ? | 417-15-13810 | • SEAL,DUST | 1 | SN: 20001- |
|||
| ? | 416-15-13751 | • COUPLING,REAR | 1 | SN: 20001- |
