| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (416-15-11003) | TRANSMISSION ASS'Y | 1 | SN: 30001- |
|||
| ? | (416-15-11002) | TRANSMISSION ASS'Y | 1 | SN: 20001-29999 |
|||
| ? | 416-15-12502 | • CLUTCH ASS'Y,1ST | 1 | SN: .- |
|||
| ? | □416-15-12501 | • CLUTCH ASS'Y,1ST | 1 | SN: 20001-. |
|||
| ? | 416-15-12512 | • • SHAFT ASS'Y | 1 | SN: .- |
|||
| ? | □416-15-12511 | • • SHAFT ASS'Y | 1 | SN: 20001-. |
|||
| ? | ☆ | • • • SHAFT | 1 | SN: 20001- |
|||
| ? | 419-15-12750 | • • • ORIFICE | 1 | SN: 10001- |
|||
| ? | ☆ | • • • HOUSING | 1 | SN: .- |
|||
| ? | ☆ | • • • HOUSING | 1 | SN: 20001-. |
|||
| ? | ☆ | • • • SPACER | 1 | SN: 10001- |
|||
| ? | 419-15-12210 | • • RING,SEAL (KIT) | 1 | SN: 10001- |
|||
| ? | 419-15-13191 | • • PISTON | 1 | SN: 10001- |
|||
| ? | 419-15-12580 | • • RING,SEAL (KIT) | 1 | SN: 10001- |
|||
| ? | 419-15-12622 | • • WASHER,THRUST | 1 | SN: .- |
|||
| ? | □419-15-12621 | • • WASHER,THRUST | 1 | SN: .-. |
|||
| ? | 419-15-12290 | • • DISC | 4 | SN: 10001- |
|||
| ? | 419-15-12310 | • • PLATE,SEPARATE | 5 | SN: 10001- |
|||
| ? | 419-15-12133 | • • SPRING,WAVE | 4 | SN: 20001- |
|||
| ? | 419-15-12280 | • • PLATE,END | 1 | SN: 10001- |
|||
| ? | 419-15-12140 | • • RING,SNAP | 1 | SN: 10001- |
|||
| ? | 417-15-12651 | • • GEAR | 1 | SN: 10001- |
|||
| ? | 419-15-12660 | • • BEARING | 2 | SN: 10001- |
|||
| ? | 419-15-12632 | • • WASHER,THRUST | 1 | SN: .- |
|||
| ? | □419-15-12631 | • • WASHER,THRUST | 1 | SN: .-. |
|||
| ? | 417-15-12662 | • • GEAR | 1 | SN: 10001- |
|||
| ? | 417-15-12670 | • • COLLAR | 1 | SN: 10001- |
|||
| ? | 417-15-12850 | • • BEARING | 1 | SN: 20001- |
|||
| ? | 06030-06210 | • • BEARING | 1 | SN: 10001- |
|||
| ? | 419-15-12121 | • RING,SEAL (KIT) | 2 | SN: 20001- |
