| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 417-06-12224 | WIRE ASS'Y | 1 | SN: 10672-11757 |
|||
| ? | □417-06-12223 | WIRE ASS'Y | 1 | SN: 10001-10671 |
|||
| ? | 421-06-11970 | • DIODE | 4 | SN: 10001-@ |
|||
| ? | 417-06-12350 | PLATE | 1 | SN: 10001-@ |
|||
| ? | 417-06-12360 | PLATE | 1 | SN: 10001-@ |
|||
| ? | 6110-23-5331 | BRACKET | 2 | SN: 10001-@ |
|||
| ? | 01010-30820 | BOLT | 4 | SN: 10001-@ |
|||
| ? | 01643-30823 | WASHER | 4 | SN: 10001-@ |
|||
| ? | 417-06-12372 | WIRE ASS'Y | 1 | SN: .-@ |
|||
| ? | ▩417-06-12371 | WIRE ASS'Y | 1 | SN: 10001-. |
|||
| ? | (417-06-12372{417-06-12550)} | ||||||
| ? | 417-06-12550 | WIRE ASS'Y | 1 | SN: .-@ |
|||
| ? | 232-06-52410 | SENSOR,OIL TEMP. AND WATER TEMP. | 2 | SN: 10673-@ |
|||
| ? | □417-06-11210 | SENSOR,OIL TEMP. AND WATER TEMP. | 2 | SN: 10001-10672 |
|||
| ? | 417-06-12381 | WIRE ASS'Y | 1 | SN: 10001-@ |
|||
| ? | 417-06-11240 | SWITCH,PARKING | 1 | SN: 10001-@ |
|||
| ? | 01010-30816 | BOLT | 2 | SN: 10001-@ |
|||
| ? | 01643-30823 | WASHER | 4 | SN: 10001-@ |
|||
| ? | 01580-00806 | NUT | 2 | SN: 10001-@ |
|||
| ? | 417-06-12391 | WIRE ASS'Y | 1 | SN: 10001-@ |
|||
| ? | 421-06-11930 | RELAY,BATTERY | 1 | SN: 10001-@ |
|||
| ? | 01010-30830 | BOLT | 2 | SN: 10001-@ |
|||
| ? | 01643-30823 | WASHER | 2 | SN: 10001-@ |
|||
| ? | 416-06-12110 | WIRE | 1 | SN: 10001-@ |
|||
| ? | 417-06-12410 | WIRE | 1 | SN: 10001-@ |
|||
| ? | 417-06-12420 | WIRE | 1 | SN: 10001-@ |
|||
| ? | 01010-31016 | BOLT | 1 | SN: 10001-@ |
|||
| ? | 01643-31032 | WASHER | 1 | SN: 10001-@ |
|||
| ? | 08038-00519 | CAP | 5 | SN: 10001-11757 |
|||
| ? | 08038-02027 | CAP | 2 | SN: 10001-@ |
|||
| ? | 08038-06031 | CAP | 3 | SN: 10001-@ |
|||
| ? | 01010-31016 | BOLT | 1 | SN: 10001-@ |
|||
| ? | 01643-31032 | WASHER | 1 | SN: 10001-@ |
|||
| ? | 08037-01610 | GROMMET | 1 | SN: 10001-@ |
|||
| ? | 08037-03614 | GROMMET | 1 | SN: 10001-@ |
|||
| ? | 08036-01414 | CLIP | 2 | SN: 10001-@ |
|||
| ? | 01010-30816 | BOLT | 2 | SN: 10001-@ |
|||
| ? | 01643-30823 | WASHER | 2 | SN: 10001-@ |
|||
| ? | 08036-01814 | CLIP | 1 | SN: 10001-@ |
|||
| ? | 01010-31220 | BOLT | 1 | SN: 10001-@ |
|||
| ? | 01643-31232 | WASHER | 1 | SN: 10001-@ |
|||
| ? | 08036-02514 | CLIP | 3 | SN: 10001-@ |
|||
| ? | 01010-31020 | BOLT | 1 | SN: 10001-@ |
|||
| ? | 01643-31032 | WASHER | 1 | SN: 10001-@ |
|||
| ? | 421-06-12910 | CLIP | 1 | SN: 10001-@ |
|||
| ? | 01220-40612 | SCREW | 1 | SN: 10001-@ |
|||
| ? | 01642-20608 | WASHER | 2 | SN: 10001-@ |
|||
| ? | 01580-10605 | NUT | 1 | SN: 10001-@ |
|||
| ? | 08036-10810 | CLIP | 2 | SN: 10001-@ |
|||
| ? | 423-06-12640 | CLIP | 1 | SN: 10001-@ |
|||
| ? | 01010-31020 | BOLT | 3 | SN: 10001-@ |
|||
| ? | 01643-31032 | WASHER | 3 | SN: 10001-@ |
|||
| ? | 08036-21814 | CLIP | 2 | SN: 10001-@ |
|||
| ? | 01010-31020 | BOLT | 2 | SN: 10001-@ |
|||
| ? | 01643-31032 | WASHER | 2 | SN: 10001-@ |
|||
| ? | 08034-00519 | BAND | 4 | SN: 10001-@ |
