| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (700-85-81001) | CONTROL VALVE | 1 | SN: 53001- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1665-01A0 T0 Y1665-04A0. | ||||||
| ? | ☆ | • VALVE SUB ASS'Y | 1 | SN: 53001- |
|||
| ? | ☆ | • • BODY SUB ASS'Y | 1 | SN: 53001- |
|||
| ? | 700-84-13960 | • • • PLUG | 1 | SN: 53001- |
|||
| ? | 700-80-64220 | • • • RING | 1 | SN: 53001- |
|||
| ? | 700-22-11410 | • • • O-RING | 1 | SN: 53001- |
|||
| ? | 07002-13034 | • • • O-RING | 1 | SN: 53001- |
|||
| ? | 07040-13316 | • • • PLUG | 1 | SN: 53001- |
|||
| ? | 07002-13334 | • • • O-RING | 1 | SN: 53001- |
|||
| ? | 07043-70108 | • • • PLUG | 1 | SN: 53001- |
|||
| ? | 07043-00312 | • • • PLUG | 2 | SN: 53001- |
|||
| ? | 709-30-62150 | • • • PLUG | 4 | SN: 53001- |
|||
| ? | 07002-12034 | • • • O-RING | 4 | SN: 53001- |
|||
| ? | 700-82-95000 | • • • DETENT ASS'Y | 1 | SN: 53001- |
|||
| ? | 700-82-96000 | • • • DETENT ASS'Y | 1 | SN: 53001- |
