| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (700-83-81002) | CONTROL VALVE | 1 | SN: 53001- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1663-01A0 T0 Y1663-04A0. | ||||||
| ? | ☆ | • VALVE SUB ASS'Y | 1 | SN: 53001- |
|||
| ? | ☆ | • • SPOOL | 2 | SN: 53001- |
|||
| ? | ☆ | • • SPOOL | 1 | SN: 53001- |
|||
| ? | 700-84-13891 | • • PLATE | 4 | SN: 53001- |
|||
| ? | 700-84-13910 | • • SEAL | 6 | SN: 53001- |
|||
| ? | 700-84-11240 | • • O-RING | 4 | SN: 53001- |
|||
| ? | 01252-30612 | • • BOLT | 6 | SN: 53001- |
|||
| ? | 700-82-11730 | • • PLATE | 2 | SN: 53001- |
|||
| ? | 700-82-11740 | • • SPACER | 2 | SN: 53001- |
|||
| ? | 700-82-11711 | • • RETAINER | 2 | SN: 53001- |
|||
| ? | 700-82-11721 | • • RETAINER | 2 | SN: 53001- |
|||
| ? | 700-84-11390 | • • COVER | 1 | SN: 53001- |
|||
| ? | 700-84-11641 | • • COLLAR | 1 | SN: 53001- |
|||
| ? | 01643-30823 | • • WASHER | 1 | SN: 53001- |
|||
| ? | 01252-30830 | • • BOLT | 1 | SN: 53001- |
|||
| ? | 700-84-11631 | • • RETAINER | 2 | SN: 53001- |
|||
| ? | 01252-30625 | • • BOLT | 2 | SN: 53001- |
|||
| ? | 700-84-11770 | • • SPRING | 2 | SN: 53001- |
|||
| ? | 700-82-11750 | • • SPRING | 1 | SN: 53001- |
|||
| ? | 01252-30630 | • • BOLT | 4 | SN: 53001- |
