| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 417-V88-2180 | LEVER | 1 | SN: 53001- |
|||
| ? | 417-43-28210 | BOOT | 1 | SN: 53001- |
|||
| ? | 421-09-21230 | NUT | 1 | SN: 53001- |
|||
| ? | 421-43-28410 | KNOB | 1 | SN: 53001- |
|||
| ? | 06124-02020 | BEARING | 2 | SN: 53001- |
|||
| ? | 417-V88-2210 | YOKE | 1 | SN: 53001- |
|||
| ? | 417-43-18181 | PIN | 1 | SN: 53001- |
|||
| ? | 01010-80655 | BOLT | 1 | SN: 53001- |
|||
| ? | 01596-00606 | NUT | 1 | SN: 53001- |
|||
| ? | 417-V88-2190 | BRACKET | 1 | SN: 53001- |
|||
| ? | 06124-02020 | BEARING | 2 | SN: 53001- |
|||
| ? | 363-43-31250 | BOLT,STOPPER | 1 | SN: 53001- |
|||
| ? | 01016-50825 | BOLT,STOPPER | 2 | SN: 53001- |
|||
| ? | 01580-10806 | NUT | 3 | SN: 53001- |
|||
| ? | 01643-31645 | WASHER | 1 | SN: 53001- |
|||
| ? | 01590-31619 | NUT | 1 | SN: 53001- |
|||
| ? | 04050-14030 | PIN,COTTER | 1 | SN: 53001- |
|||
| ? | 417-V88-2230 | LEVER | 1 | SN: 53001- |
|||
| ? | 04025-00520 | PIN,SPRING | 1 | SN: 53001- |
