| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 425-07-21151 | ..DUCT ASS'Y,AIR | 2 | SN: 53001-53714 |
|||
| ? | ND145820-9610 | ...DUCT,AIR | 1 | SN: 53001-@ |
|||
| ? | ND145820-8330 | ...DUCT,AIR | 1 | SN: 53001-@ |
|||
| ? | ND116730-0690 | ...DAMPER ASS'Y | 1 | SN: 53001-53714 |
|||
| ? | ND116730-0700 | ...DAMPER ASS'Y | 1 | SN: 53001-53714 |
|||
| ? | ND017732-4840 | ...LEVER,CONTROL | 1 | SN: 53001-53714 |
|||
| ? | ND017732-4850 | ...LEVER,CONTROL | 1 | SN: 53001-53714 |
|||
| ? | ND017732-4860 | ...LEVER,CONTROL | 1 | SN: 53001-53714 |
|||
| ? | ND017732-4870 | ...LEVER | 1 | SN: 53001-53714 |
|||
| ? | ND116662-0640 | ...SHAFT | 1 | SN: 53001-@ |
|||
| ? | ND949008-0420 | ...SCREW,TAPPING | 2 | SN: 53001-@ |
|||
| ? | ND913100-3081 | ...SCREW,WITH WASHER | 2 | SN: 53001-@ |
|||
| ? | ND116632-0171 | ...SPRING,HOLDING | 8 | SN: 53001-@ |
|||
| ? | ND063700-6570 | ...SERVO MOTOR ASS'Y | 1 | SN: 53001-53714 |
|||
| ? | ND949008-0780 | ...SCREW,TAPPING | 1 | SN: 53001-@ |
|||
| ? | ND146625-2630 | ...BUSHING | 1 | SN: 53001-53714 |
|||
| ? | ND246690-2930 | ...CLAMP | 2 | SN: 53001-53714 |
|||
| ? | ND017773-0140 | ...CLIP | 1 | SN: 53001-@ |
|||
| ? | ND116662-4210 | ...SHAFT | 1 | SN: 53001-53714 |
|||
| ? | ND949202-0940 | ...BUSHING | 1 | SN: 53001-53714 |
|||
| ? | ND146522-6180 | ...BRACKET | 1 | SN: 53001-53714 |
|||
| ? | ND909400-5161 | ...SCREW,TAPPING | 3 | SN: 53001-53714 |
