| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (419-923-2030) | CAB ASS'Y | 1 | SN: 53715-55000 |
|||
| ? | (□418-923-2030) | CAB ASS'Y | 1 | SN: 53001-53714 |
|||
| ? | THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210-31A1 TO K0210-45A1. | ||||||
| ? | (419-923-2500) | • DOOR ASS'Y,R.H. | 1 | SN: 53715-55000 |
|||
| ? | (□418-923-2500) | • DOOR ASS'Y,R.H. | 1 | SN: 53001-53714 |
|||
| ? | THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210-41A1 TO K0210-43A1. | ||||||
| ? | 418-923-2710 | • • COVER | 1 | SN: 53001-55000 |
|||
| ? | 421-09-21410 | • • SCREW | 2 | SN: 53001-55000 |
|||
| ? | 418-923-2720 | • • COVER | 1 | SN: 53001-55000 |
|||
| ? | 421-09-21410 | • • SCREW | 4 | SN: 53001-55000 |
|||
| ? | 418-923-2740 | • • PAD,R.H. | 1 | SN: 53001-55000 |
|||
| ? | 419-54-16730 | • • • CLIP,TRIM | 5 | SN: 53001-55000 |
|||
| ? | 205-54-72220 | • • HANDLE | 1 | SN: 53001-55000 |
|||
| ? | 01023-60616 | • • SCREW | 2 | SN: 53001-55000 |
|||
| ? | 418-56-21111 | • • PLATE | 1 | SN: 53001-55000 |
|||
| ? | 423-56-21750 | • • SPRING | 1 | SN: 53001-55000 |
|||
| ? | 01435-00610 | • • BOLT | 4 | SN: 53001-55000 |
|||
| ? | 01010-80612 | • • BOLT | 1 | SN: 53001-55000 |
|||
| ? | 427-W93-1770 | • • WASHER | 1 | SN: 53001-55000 |
|||
| ? | 01643-31232 | • • WASHER | 1 | SN: 53001-55000 |
|||
| ? | 421-56-11652 | • • BUSHING | 1 | SN: 53001-55000 |
|||
| ? | 421-62-14740 | • • WASHER | 1 | SN: 53001-55000 |
|||
| ? | 01596-01009 | • • NUT | 1 | SN: 53001-55000 |
|||
| ? | 418-923-2630 | • • CUSHION | 1 | SN: 53001-55000 |
|||
| ? | 418-923-2880 | • • SEAL | 1 | SN: 53001-55000 |
|||
| ? | 417-56-21540 | • • HINGE | 2 | SN: 53001-55000 |
|||
| ? | 01010-80825 | • • BOLT | 4 | SN: 53001-55000 |
|||
| ? | 01643-30823 | • • WASHER | 4 | SN: 53001-55000 |
