| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (363-17-31402) | PUMP ASS'Y,(A4VG28DA-931-0) | 1 | SN: 21212- KIT-FLAG: _- SERIALNO: 21212- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1610-02A0A T0 Y1610-06A0A . | SERIALNO: |
|||||
| ? | THE UCHIDA YUATSU KIKI PART NUMBER IS THAT UC IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW. | SERIALNO: |
|||||
| ? | (UCBA041S9146-0) | • PUMP ASS'Y,PISTON | 1 | SN: 21212- KIT-FLAG: _- SERIALNO: 21212- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1610-02A0A T0 Y1610-06A0. | SERIALNO: |
|||||
| ? | UC4704375889 | • • ROTARY ASS'Y | 1 | SN: 21212- KIT-FLAG: _- SERIALNO: 21212- |
|||
| ? | UC4704354498 | • • • CYLINDER ASS'Y | 1 | SN: 21212- KIT-FLAG: _- SERIALNO: 21212- |
|||
| ? | UC4704315415 | • • • PISTON ASS'Y | 9 | SN: 21212- KIT-FLAG: _- SERIALNO: 21212- |
|||
| ? | UC4704355088 | • • • HANGER ASS'Y | 1 | SN: 21212- KIT-FLAG: _- SERIALNO: 21212- |
|||
| ? | UC1704323552 | • • • SPRING | 1 | SN: 21212- KIT-FLAG: _- SERIALNO: 21212- |
|||
| ? | UC1704152653 | • • • SHAFT | 1 | SN: 21212- KIT-FLAG: _- SERIALNO: 21212- |
|||
| ? | UC1704198246 | • • • CASE,SEAL | 1 | SN: 21212- KIT-FLAG: _- SERIALNO: 21212- |
|||
| ? | UC1704139201 | • • • PIN | 2 | SN: 21212- KIT-FLAG: _- SERIALNO: 21212- |
|||
| ? | UC1704321419 | • • • RETAINER | 1 | SN: 21212- KIT-FLAG: _- SERIALNO: 21212- |
|||
| ? | UC1704313427 | • • • GUIDE | 1 | SN: 21212- KIT-FLAG: _- SERIALNO: 21212- |
|||
| ? | UC1706500494 | • • • GUIDE | 1 | SN: 21212- KIT-FLAG: _- SERIALNO: 21212- |
|||
| ? | UC1100361998 | • • • PLATE,CONTROL | 1 | SN: 21212- KIT-FLAG: _- SERIALNO: 21212- |
|||
| ? | UC1701566059 | • • • BEARING | 1 | SN: 21212- KIT-FLAG: _- SERIALNO: 21212- |
|||
| ? | UC1701566251 | • • • BEARING | 2 | SN: 21212- KIT-FLAG: _- SERIALNO: 21212- |
|||
| ? | 04064-02512 | • • • RING,SNAP | 1 | SN: 21212- KIT-FLAG: _- SERIALNO: 21212- |
|||
| ? | 04065-06825 | • • • RING,SNAP | 1 | SN: 21212- KIT-FLAG: _- SERIALNO: 21212- |
|||
| ? | UC1100354339 | • • • SEAL,OIL | 1 | SN: 21212- KIT-FLAG: _- SERIALNO: 21212- |
|||
| ? | UC1300271009 | • • • O-RING | 1 | SN: 21212- KIT-FLAG: _- SERIALNO: 21212- |
|||
| ? | UC1704350022 | • • • SHIM,0.6MM | 1 | SN: 21212- KIT-FLAG: _- SERIALNO: 21212- |
|||
| ? | UC1100474589 | • • • SHIM,0.7MM | 1 | SN: 21212- KIT-FLAG: _- SERIALNO: 21212- |
|||
| ? | UC1704350013 | • • • SHIM,0.8MM | 1 | SN: 21212- KIT-FLAG: _- SERIALNO: 21212- |
|||
| ? | UC1100474599 | • • • SHIM,0.9MM | 1 | SN: 21212- KIT-FLAG: _- SERIALNO: 21212- |
|||
| ? | UC1704350004 | • • • SHIM,1.0MM | 1 | SN: 21212- KIT-FLAG: _- SERIALNO: 21212- |
|||
| ? | UC1100474609 | • • • SHIM,1.1MM | 1 | SN: 21212- KIT-FLAG: _- SERIALNO: 21212- |
|||
| ? | UC1704329999 | • • • SHIM,1.2MM | 1 | SN: 21212- KIT-FLAG: _- SERIALNO: 21212- |
